Incorporation of Hybrid Pre-Dispersed Organo-Montmorillonite/ Destabilized Bentonite Nanofillers for Improving Tensile Strength of PEVA Copolymer with 40% Vinyl Acetate Composition

Abstract:

In this work, soft and flexible poly (ethylene-co-vinyl acetate) (PEVA) with 40% vinyl acetate (VA) composition was used as matrix material to form nanocomposites with single nanofiller (organo-montmorillonite (OMMT) or Bentonite (Bent)) and hybrid nanofillers (OMMT+Bent in the ratios of 4:1, 3:2, 2:3 and 1:4). In order to achieve greater exfoliation and dispersion of the hybrid nanofillers in the PEVA matrix, the pre- dispersing and destabilization technique was applied to the O-MMT and Bent, respectively. The procedures were done prior to the melt compounding process of the nanocomposite. A tensile test was done to evaluate the mechanical properties of the resultant nanocomposites and to allow the selection of the best OMMT/Bent ratio for the production of the hybrid nanocomposite. The structure and fractured surfaces of the neat PEVA and nanocomposite were analyzed using Fourier Transform Infrared (FTIR) and Scanning Electron Microscopy (SEM), respectively. Results indicated that the addition of hybrid pre-dispersed OMMT/destabilized bentonite nanofillers into the PEVA matrix resulted in greater mechanical performance as compared to the single OMMT or single Bent nanofiller. The best achievement in the tensile strength and elongation at break of the PEVA hybrid nanocomposite was obtained when the hybrid nanofillers was added in the ratio of 4:1 (OMMT: Bent). The SEM analysis showed that the PEVA hybrid nanocomposite with 4OMMT: 1Bent had greater matrix deformation than the neat PEVA when subjected to tensile load. This mechanical deformation could be related to the increased flexibility of the PEVA chains which facilitated more energy absorption during the stretching of the material. Apparently, this mechanism acted as a matrix toughening process which allowed the increment of both tensile strength and elongation at break values of the PEVA upon the addition of the hybrid nanofillers.

• Periodical: Materials Science Forum (Volume 1010)
• Pages: 118-123
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1010.118
• Online since: September 2020
• Authors: Tuty Fareyhynn Mohammed Fitri*, Azlin Fazlina Osman, Rahimah Othman, Zaleha Mustafa
• Keywords: Bentonite, Hybrid Nanofillers, Organo-Montmorillonite, Poly(Ethylene-co-Vinyl Acetate)

References

[1] H. M. Lee, B. J. Park, H. J. Choi, R. K. Gupta and S. T. Bhattachary, Preparation and characteristics of ethylene-vinyl acetate copolymer/organoclay nanocomposites. J. of Macromolecular Sci. Part-B-Phy. 4 (2007) 261-273.

DOI: 10.1080/00222340601066956

[2] J. K. Fink, Ethylene Vinyl Acetate Copolymers, in Handbook of Engineering and Specialty Thermoplastics: Polyolefins and Styrenics, John Wiley & Sons, Inc., Hoboken, NJ, USA, 2010, pp.187-209.

DOI: 10.1002/9780470881712.ch7

[3] I.D. Ibrahim, E. R. Sadiku, T. Jamir, A. Hamam and W. K. Kupolati, Applications of polymers in the biomedical field. Curr Trends Biomedical Eng & Biosci. 4 (2017) 9-11.

[4] E. Marques and P. J. Mancha, Ethylene-vinyl acetate foam as a new lung substitute in radiotherapy. The Int J. of Med. Phys. Research & Practice. 45 (2018) 1715-1723.

DOI: 10.1002/mp.12781

[5] R. Othman, G. T. Vladisavljenic, N. L. Thomas and Z. K. Nagy, Fabrication of composite poly(d,l-lactide)/montmorillonite nanoparticles for controlled delivery of acetaminophen by solvent-displacement method using glass capillary microfluidics. Colloids and Surface B:Biointerfaces. 141(2016) 187-195.

DOI: 10.1016/j.colsurfb.2016.01.042

[6] A. F. Osman, A. R. A. Hamid, M. Rakibuddin, G. Khung Weng, R. Ananthakrishnan, S. A. Ghani and Z. Mustafa, Hybrid silicate nanofillers: Impact on morphology and performance of EVA copolymer upon in vitro physiological fluid exposure. J. of Applied Polymer Sci. 134 (2017) 44640.

DOI: 10.1002/app.44640

[7] A. A. A. Fauzi, A.F. Osman, M. A. A. Abdullah, S. Mandal and R. Ananthakrishnan, Ethylene vinyl acetate nanocomposites with hybrid silicate nanofillers of destabilized natural and commercial bentonites and organomontmorillonites. J. of Vinyl & Addit Technol (2019).

DOI: 10.1002/vnl.21708

[8] T.F. Mohammed Fitri, A. F. Osman, R. Othman and K. A. Abdul Halim, Tensile Toughness Improvement of Poly(ethylene-co-vinyl acetate)(PEVA) by Incorporation of Hybrid Pre-dispersed O-MMT and Destabilized Bentonite, IOP Conf. Ser.: Mater. Sci. Eng. 551 (2019) 012085.

DOI: 10.1088/1757-899x/551/1/012085
