Research on Ultimate Thinning Rate of Superalloy Spinning

Abstract:

Spinning forming is an effective method for processing thin-walled rotating body parts. The influence of process parameters on the spinning forming limit of materials was studied for the four high-temperature alloys of GH3044, GH3625, GH3536 and GH4169 used in aero-engines. The results can be used as aero-engine high-temperature alloy parts spinning process and provides experimental basis and process guidance. The research results showed that the forming temperature had a significant effect on the spinning forming performance of superalloy materials. When the temperature increased to 800°C and above, the ultimate thinning rate raised 70%. The ultimate thinning rate of GH4169 was higher than the other three materials and GH3044 and GH3536 was at the middle level, GH3625 was relatively low. At the same time, the feed ratio and the corner radius of the rotary wheel had a certain influence on the ultimate thinning rate of different superalloys. The spinning process needs to select reasonable process parameters according to the actual situation when the spinning is applied to manufacture parts.

You might also be interested in these eBooks

Functional and Functionally Structured Materials V

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1035)

Pages:

152-160

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.1035.152

Citation:

Cite this paper

Online since:

June 2021

Authors:

Hai Bao Wu*, Fu Long Chen, De Gui Liu, Ji Zhen Li, Jian Fei Wang

Keywords:

Power Spinning, Spinability, Superalloy, Ultimate Thinning Rate

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Zhu Ningyuan et al, Hot-spinning forming technology and research status of difficult-to-deformed metal. Forging Technology, 2014. 39(09): 42-47.

Google Scholar

[2] Qi Huan, Development and Process of Inconel 718 (GH4169) Superalloy. Materials Engineering, 2012. (08): 92-100.

Google Scholar

[3] Li Yafei and Chen Hui, Research on the rotatability of a curved thin-walled profiled piece. Modern Manufacturing Engineering, 2005(06): 55-57.

Google Scholar

[4] Zhao Wei, Hot Spinning Process and Its Application. Mold Manufacturing, 2012. 12(11): 37-39.

Google Scholar

[5] Zhang Cheng et al. Application and development of Titanium alloy spinning technology in the domestic aerospace field. Solid Rocket Technology, 2013. 36(01): 127-132.

Google Scholar

[6] Li Jizhen, Opportunities and Challenges of Spinning Technology in China. Forging and Stamping, 2017(12): 18-21.

Google Scholar
