Influence of Ca and Ce Additions on Microstructure and Microhardness of Squeeze-Cast AZ91 Mg Alloy

Abstract:

In this study, AZ91 alloy was used as the base material and calcium and cerium were added as alloying elements. Microstructural analysis through optical microscope (OM) and field emission scanning electron microscope (FESEM) revealed that AZ91 base alloy contains α-Mg matrix and β-Mg₁₇Al₁₂ interdendritic network. The inclusion of individual calcium and cerium resulted in a more homogeneous distribution of the interdendritic network in the AZ91-1wt.% Ca and AZ91-1wt.% Ce alloy. The secondary phase (Mg₁₇Al₁₂) was refined in the microstructure as a result of Ca and Ce addition where Ce addition forms a new rod-like phase that is recognized as Al₁₁Ce₃ and Ca addition forms a skeleton like structure of Mg₁₇Al₁₂ and Al₂Ca. Due to the formation of new Al₂Ca and Al₁₁Ce₃ intermetallics, the volume fraction of β-Mg₁₇Al₁₂ was more suppressed with Ca and Ce alloy additions. The grain size determined from Electron Backscatter Diffraction (EBSD) maps indicate the reduction in average grain size with individual Ca and Ce additions. The addition of these elements was found to improve the hardness of AZ91 alloy. Overall, the results of this study demonstrate the potential for using Calcium and Cerium as alloying elements in AZ91 alloy to improve its mechanical properties by modifying its microstructure.

• Periodical: Materials Science Forum (Volume 1098)
• Pages: 29-39
• DOI: https://doi.org/10.4028/p-6tQl0e
• Online since: September 2023
• Authors: Namrata Sarania, Ankush S. Marodkar, Hemant Borkar*
• Keywords: AZ91 Alloy, Grain Refinement, Hardness, Magnesium, Squeeze Casting

References

[1] L. Shengfa, K. Liugen, H. Hui, W. Zhongfan, The Role of Calcium in Microstructural Refinement of AZ91 Magnesium Alloy, Journal of Wuhan University of Technology - Mater. Sci. Ed. 21 (4) (2006) 45-47

DOI: 10.1007/BF02841202

[2] R. Xiao, W. Liu, G. Wu, L. Zhang, B. Liu, W. Ding, Effect of Ca content and rheo-squeeze casting parameters on microstructure and mechanical properties of AZ91−1Ce−xCa alloys, Trans. Nonferrous Met. Soc. China 31(2021) 1572−1586. https://doi.org/10.1016/S1003-6326 (21) 65599-1

DOI: 10.1016/s1003-6326(21)65599-1

[3] K. Hirai, H. Somekawa, Y. Takigawa, K. Higashi, Effects of Ca and Sr addition on mechanical properties of a cast AZ91 magnesium alloy at room and elevated temperature, Mater. Sci. Eng. A 403 (2005) 276–280

DOI: 10.1016/j.msea.2005.05.028

[4] E. Tolouie, R. Jamaati, Effect of β–Mg17Al12 phase on microstructure, texture and mechanical properties of AZ91 alloy processed by asymmetric hot rolling, Mater. Sci. Eng. A S0921-5093(18)31297-8

DOI: 10.1016/j.msea.2018.09.086

[5] A. S. Marodkar, H. Patil, H. Borkar, Effect of Squeeze Casting and Combined Addition of Calcium and Strontium on Microstructure and Mechanical Properties of AZ91 Magnesium Alloy, Int. J. Met. (2023) 1-19

DOI: 10.1007/s40962-022-00943-1

[6] Y. Cubides, A. I. Karayan, M.W. Vaughan, I. Karaman, H. Castaneda, Enhanced mechanical properties and corrosion resistance of a fine-grained Mg-9Al-1Zn alloy: the role of bimodal grain structure and 𝛽-Mg17Al12 precipitates, Materialia 13 (2020) 100840

DOI: 10.1016/j.mtla.2020.100840

[7] Y. Zhang, G. Wu, W. Liu, L. Zhang, S. Pang, Y. Wang, W. Ding, Effects of processing parameters and Ca content on microstructure and mechanical properties of squeeze casting AZ91–Ca alloys, Mater. Sci. Eng. A 595 (2014) 109–117. https://doi.org/

DOI: 10.1016/j.msea.2013.12.014

[8] H. Hu, Squeeze casting of magnesium alloys and their composites, J. Mater. Sci. 33 (1998) 1579-1589

DOI: 10.1023/A:1017567821209

[9] A. S. Marodkar, H. Patil, J. Chavhan, H. Borkar, Effect of gravity die casting, squeeze casting and extrusion on microstructure, mechanical properties and corrosion behaviour of AZ91 magnesium alloy, Mater. Today: Proceedings (2023)

DOI: 10.1016/j.matpr.2023.03.053

[10] W. Huang, H. Yan, Effect of Cerium Addition on Microstructure and Mechanical Properties of Die-cast AM60 Alloy, International Conference on Electronic & Mechanical Engineering and Information Technology (2011)

DOI: 10.1109/EMEIT.2011.6023632

[11] Z. Feng, E. Wang, M. Zhang, X. Li and C. Su, Effect of Ce on Microstructure and Mechanical Properties of AZ91 Magnesium Alloy, JPCS 2174 (2022) 012060

DOI: 10.1088/1742-6596/2174/1/012060

[12] C. Huisheng, G. Feng, R. Xiushan, S. Juan, C. Baodong, Effects of cerium on as-cast microstructure of AZ91 magnesium alloy under different solidification rates, J. Rare Earths, 34 (7) (2016) 736-741

DOI: 10.1016/S1002-0721(16)60085-6

[13] R. Ninomiya, T. Ojiro, K. Kubota, Improved heat resistance of Mg-Al alloys by the Ca addition, Acta. metall. mater. 43 (2) (1995) 669-674

DOI: 10.1016/0956-7151(94)00269-N

[14] G. Wu, Y. Fan, H. Gao, C. Zhai, Y. P. Zhu, The effect of Ca and rare earth elements on the microstructure, mechanical properties and corrosion behavior of AZ91D, Mater. Sci. Eng. A 408 (2005) 255–263

DOI: 10.1016/j.msea.2005.08.011

[15] C.H. Caceres, J.R. Griffiths, A.R. Pakdel, C.J. Davidson, Microhardness mapping and the hardness-yield strength relationship in high-pressure diecast magnesium alloy AZ91, Mater. Sci. Eng. A 402 (2005) 258–268

DOI: 10.1016/j.msea.2005.04.042

[16] H. Zengin, Y. Turen, L. Elen, A Comparative Study on Microstructure, Mechanical and Tribological Properties of A4, AE41, AS41 and AJ41 Magnesium Alloys, J. Mater. Eng. Perform. (2019)

DOI: 10.1007/s11665-019-04223-8

[17] V. Chaturvedi, A. Sharma, U. Pande, Effect of Vibrations on Grain Refinement of AZ91 Mg Alloy, Mater. Res. Express (2017)

DOI: 10.1088/2053-1591/aa64f5
