Application of a Discrete Finite Element Modeling Approach to Form a Near-Uniform Thickness Compound Curvature Composite Part

Abstract:

Thermoforming of thermoplastic fiber-reinforced composites enables cost-effective production of complex, high-volume components, yet wrinkling and shear-induced thickness variations remain persistent challenges in compound-curvature geometries, often leading to nonuniform consolidation. This work presents a predictive virtual process simulation that integrates discrete mesoscopic finite element modeling with targeted blank design strategies to address these limitations. The approach, developed by the Sherwood Group and implemented in LS-DYNA, is applied to the thermoforming of a UHMWPE unidirectional cross-ply composite system (DSM® Dyneema® HB210). A thickness-stretch shell formulation (SHELL ELFORM25), coupled with a user-defined material model, is employed to simultaneously capture in-plane shear, through-thickness deformation, and frictional interactions during forming. A parametric study is conducted to evaluate the combined effects of tooling geometry and strategically introduced slits in the blank, including side-and corner-oriented configurations. The results demonstrate that the proposed formulation provides an effective balance between computational efficiency and predictive accuracy while explicitly reducing shear-induced thickening. Notably, corner-oriented slits at 45° to the fiber directions significantly reduced thickness variability and wrinkle severity compared to unmodified blanks and side-slit configurations. These findings highlight the novelty of integrating thickness-aware forming simulations with geometric blank modification as a robust pathway for achieving near-uniform thickness and improved preform quality in thermoformed composite parts.

• Periodical: Materials Science Forum (Volume 1182)
• Pages: 73-82
• DOI: https://doi.org/10.4028/p-C1cyX0
• Online since: April 2026
• Authors: Kari D. White, James A. Sherwood*
• Keywords: Composite, Consolidation, Finite Element, Thermoforming, Thermoplastic
