The Indentation Behavior of Closed-Cell Al Foam under the Flat-End Cylindrical Indenter

Abstract:

The indentation response of the closed-cell Al foam under the flat-end cylindrical indenter is examined by use the finite element method. The MSC/Marc finite element package is used to model the indentation response of the foam panels, and the Al foam was defined in MSC/Marc as the homogeneous, elasto-plastic material. The simulation result reveals that the deformation was found to be almost totally restricted to a spherical cap-shape compacted zone under the indenter, and the shape of the deformation zone is similar to the observed phenomenon from the indentation test.

You might also be interested in these eBooks

Physical and Numerical Simulation of Material Processing VI

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 704-705)

Pages:

960-966

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.704-705.960

Citation:

Cite this paper

Online since:

December 2011

Authors:

Xin Zhu Wang, Guang Tao Zhou

Keywords:

Al Foam, Finite Element Method (FEM), Indentation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] L. J. Gibson, M. F. Ashby: Cellular Solids: Structure and Properties, 2nd edition (Cambridge University Press, UK 1997).

Google Scholar

[2] M. F. Ashby, A. G. Evans, N. A. Fleck, L. J. Gibson, J. W. Hutchinson and H. N. G. Wadley: Metal Foams: A Design Guide (Butterworth-Heinemann, UK 2000).

DOI: 10.1016/b978-075067219-1/50001-5

Google Scholar

[3] O. B. Olurin, F. A. Fleck and M. F. Ashby: Scripta Materialia Vol. 43 (2000), p.983.

DOI: 10.1016/s1359-6462(00)00519-4

Google Scholar

[4] E. W. Andrews, G. Gioux, P. Onck and L. J. Gibson: Int J Mechanical Sciences Vol. 43 (2001), p.701.

Google Scholar

[5] S. Ramachandra, P. Sudheer and U. Ramamurty: Scripta Materialia Vol. 49 (2003), p.741.

Google Scholar

[6] Q. M. Li, R. N. Maharaj and S. R. Reid: Int J Vehicle Design Vol. 37 (2005), p.175.

Google Scholar

[7] Y. W. Kwon, G. W. Wojcik: J Compos Mater Vol. 32 (1998), p.406.

Google Scholar

[8] R. Olsson: J Sandwich Struct Mater Vol. 4 (2002), p.3.

Google Scholar

[9] R. Olsson, in: Methodology for predicting the residual strength of impacted sandwich panels. FFA TN 1999-08, the Aeronautical Research Institute of Sweden, (1999).

Google Scholar

[10] R. E. Miller: Int J Mech Sci Vol. 42 (2000), p.729.

Google Scholar

[11] P. Sudheer Kumar, S. Ramachandra and U. Ramamurty: Materials Science and Engineering A Vol. 347 (2003), p.330.

Google Scholar

[12] O. B. Olurin, N. A. Fleck and M. F. Ashby: Mater Sci Eng. A Vol. 291 (2000), p.136.

Google Scholar

[13] Wang Xin-Zhu, Wu Lin-Zhi and Wang Shi-Xun: Materials for Mechanical Engineering Vol. 33 (2009), p.469.

Google Scholar
