The Structural Characterization and Optical Properties of Zinc Oxide Films Synthesized by Electrochemistry Method

Abstract:

Flaky ZnO thin films were electrodeposited from an aqueous solution of zinc nitrate (Zn (NO₃)₂) as electrolyte on ITO glass substrate by cathodic reduction method The effect of electrolyte concentration on the structure, morphology and optical properties of ZnO thin films were studied by X-ray diffraction, scanning electron microscopy and UV-Vis spectrometer. The results show that the ZnO films are of hexagonal wurtzite structure; When the concentration of Zn (NO₃)₂ solution is 0.24 M, the sparse flaky ZnO thin films were prepared and the thickness and length of ZnO flaky are about 50 nm and 1~3 μm, respectively; When the electrolyte concentration is 0.16 M, hexagonal and triangular structures are observed and some lathy and conical ZnO structure start to appear; When the concentration of Zn (NO₃)₂ solution drops to 0.08 M, the matrix of films is still flaky ZnO, but porous structures among the flaky structures appear and the size of conical ZnO has changed, whose bottom diameter reaches 1~3 μm and length is 2~4 μm; UV-Vis absorption test results indicate the absorption peak and the bandgap of the prepared ZnO thin films are about 350 nm and 3.28 eV, respectively.

• Periodical: Materials Science Forum (Volumes 743-744)
• Pages: 926-931
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.743-744.926
• Online since: January 2013
• Authors: Jing Xia Zheng, Xing Guo Zhao, Wei Liang, Jin Bo Xue
• Keywords: Electrochemical Deposition, Morpholoy, Optical Property, ZnO Thin Film

References

[1] K. Takahashi, T. Nishi, S. Suzaka, Y. Sigeyama, T. Yamaguchi, J. Nakamura, K. Murata, Performance improvement by inserting an electrodeposited ZnO into ITO/organic solid interface in organic solid-state solar cells, Chem. Lett. 34 (2005) 768-769.

DOI: 10.1246/cl.2005.768

[2] G. Kenanakis, D. Vernardou, E. Koudoumas, G. Kiriakidis, N. Katsarakis, Ozone sensing properties of ZnO nanostructures grown by the aqueous chemical growth technique, Sens. Actuator, B. 124 (2007) 187-191.

DOI: 10.1016/j.snb.2006.12.033

[3] X.H. Wang, S. Liu, P. Chang, Y. Tang, Influence of S incorporation on the luminescence property of ZnO nanowires by electrochemical deposition, Phys. Lett. A. 372 (2008) 2900-2903.

DOI: 10.1016/j.physleta.2007.12.047

[4] S.C. Pillai, J.M. Kelly, D.E. McCormack, P. O'Brien, R. Ramesh, The effect of processing conditions on varistors prepared from nanocrystalline ZnO, J. Mater. Chem. 13 (2003) 2586-2590.

DOI: 10.1039/b306280e

[5] K.L. Chopra, S. Major, D.K. Pandya, Transparent conductors-A status review, Thin Solid Films. 102 (1983) 1-46.

DOI: 10.1016/0040-6090(83)90256-0

[6] Y.P. Fang, X.G. Wen, S.H. Yang, Q.J. Pang, et al., Hydrothermal synthesis and optical properties of ZnO nanostructured films directly grown from/on zinc substrates, J. Sol-Gel Sci. Technol. 36 (2005) 227-234.

DOI: 10.1007/s10971-005-3563-7

[7] H.W. Suh, G.Y. Kim, Y.S. Jung, W.K. Choi, et al., Growth and properties of ZnO nanoblade and nanoflower prepared by ultrasonic pyrolysis, J. Appl. Phys. 97 (2005) 044305-044310.

DOI: 10.1063/1.1849825

[8] R. Tena-Zaera, J. Elias, G. Wang, C. Levy-Clement, et al., Role of chloride ions on electrochemical deposition of ZnO nanowire arrays from O2 reduction, J. Phys. Chem. C. 111 (2007) 16706-16711.

DOI: 10.1021/jp073985g

[9] S.M. Peng, Y.K. Su, L.W. Ji, C.Z. Wu, W.B. Cheng, W.C. Chao, ZnO nanobridge array UV photodetectors, J. Phys. Chem. C. 114 (2010) 3204-3208.

DOI: 10.1021/jp909299y

[10] J.Y. Lao, J.Y. Huang, D.Z. Wang, Z.F. Ren, D. Steeves, B. Kimball, W. Porter, ZnO nanowalls, J. Appl. Phys. A. 78 (2004) 539-542.

DOI: 10.1007/s00339-003-2391-2

[11] P.F. Carcia, R.S. McLean, M.H. Reilly, et al., Transparent ZnO thin-film transistor fabricated by rf magnetron sputtering, Appl. Phys. Lett. 82 (2003) 1117-1119.

DOI: 10.1063/1.1553997

[12] X. Yang, X.F. Xu, E.J. Liang, et al., The growth and study of the optical and electrical properties of the ZnO: Fe thin films, Chinese Journal of Light Scattering. 19 (2007) 60-64.

[13] M. Krunks, E. Mellikov, Zinc oxide thin films by the spray pyrolysis method, Thin Solid Films. 270 (1995) 33-36.

DOI: 10.1016/0040-6090(95)06893-7

[14] J.S. Kim, H.A. Marzouk, P.J. Reucroft, et al., Characterization of high quality c axis oriented ZnO thin films grown by metal organic chemical vapor deposition using zinc acetate as source material, Thin Solid Films. 217 (1992) 133-137.

DOI: 10.1016/0040-6090(92)90619-m

[15] S.W. Li, K. Koike, Growth and Characterization of ZnO Films Materials, Chinese Journal of Liquid Crystal and Displays. 19 (2004) 178-181.

[16] L.L. Xu, Y. Guo, Q. Liao, et al., Morphological control of ZnO Nanostructures by Electrodeposition, J. Phys. Chem. B. 109 (2005) 13519-13522.

DOI: 10.1021/jp051007b

[17] B.N. Illy, B. Ingham, M.P. Ryan, Effect of supersaturation on the growth of zinc oxide nanosrructured films by electrochemical deposition, Cryst. Growth Des. 10 (2010) 1189-1193.

DOI: 10.1021/cg901156z

[18] I. Chakraborty, S.P. Moulik, On PbS nanoparticles formed in the compartments of water AOT n-heptane microemulsion, J. Nanopart. Res. 7 (2005) 237-247.

DOI: 10.1007/s11051-005-3472-2

[19] T. Shiosaki, S. Ohnishi, A. Kawabata, Optical properties of single-crystal ZnO film smoothly chemical-vapor deposited on intermedistely sputtered thin ZnO film on sapphire, J. Appl. Phys. 50 (1979) 3113-3117.

DOI: 10.1063/1.326391

[20] J. Aranovich, A. Ortiz, R.H. Bube, Optical and electrical properties of ZnO films prepared by spray pyrolysis for solar cell applications, J. Vac. Sci. Technol. 16 (1979) 994-1003.

DOI: 10.1116/1.570167

[21] Y. Natsume, H. Sakata, Zinc oxide films prepared by sol-gel spin-coating, Thin Solid Films. 372 (2000) 30-36.

DOI: 10.1016/s0040-6090(00)01056-7
