Purification of Multicrystalline Silicon by Cold Crucible Directional Solidification and Impurity Distribution

Abstract:

In order to get solar grade silicon, large cold crucible has been used in an induction heat furnace. By controlling the relative location of the crucible and coils, directional solidification was realized. More than 200 kg multi-crystalline silicon ingot was produced in a batch with short work time. The removal rate of most metal impurities was high, typically higher than 99% for transition metals like iron. Non-metallic elements such as boron and phosphorus could not be removed efficiently because of larger equilibrium segregation coefficient. The concentration of phosphorus was one third of the feedstock due to the vaporization in the melting process. The distribution of impurities agreed with the solidification principle. Quartzes and carbon was not used, which ensured silicon prevent from the contamination. Cooperated with other methods, large scale of solar grade silicon was produced.

• Periodical: Materials Science Forum (Volumes 743-744)
• Pages: 886-891
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.743-744.886
• Online since: January 2013
• Authors: Tong Liu, You Wen Zhao, Zhi Yuan Don, Teng Chen, Jun Wang, Hui Xie
• Keywords: Cold Crucible, Directional Solidification, Impurity Distribution, Solar Grade Silicon

References

[1] A. Goetzberger, C. Hebling, Photovoltaic materials, past, present, future, Solar Energy Materials & Solar Cells 62 (2000) 1-19.

DOI: 10.1016/s0927-0248(99)00131-2

[2] A. Goetzberger, C. Hebling, H W. Schock, Photovoltaic Materials, History, Status and Outlook, Materials Science and Engineering 40 (2003) 1.

DOI: 10.1016/s0927-796x(02)00092-x

[3] H.J. Moller, C. Funke, M. Rinio, S. Scholz, Multicrystalline silicon for solar cells, Thin Solid Films 87 (2005) 179-187.

DOI: 10.1016/j.tsf.2005.01.061

[4] S. Pizzini, Towards solar grade silicon: challenges and benefit for low cost photovoltaics, Solar Energy Materials and Solar Cells 9(2010) 1528-1533.

DOI: 10.1016/j.solmat.2010.01.016

[5] N. Yuge, M. Abe, K. Hanazawa, et al., Purification of metallurgical grade silicon up to solar grade. Progress in Photovoltaics: Research and Applications, 9 (2001) 203.

DOI: 10.1002/pip.372

[6] B. Gao, X.J. Chen, S. Nakano, K. Kakimoto, Crystal growth of high purity multicrystalline silicon using a unidirectional solidification furnace for solar cells, Journal of Crystal Growth 312 (2010) 1572-1576.

DOI: 10.1016/j.jcrysgro.2010.01.034

[7] M.A. Martoranoa, J.B. Ferreira Neto, T.S. Oliveira, T.O. Tsubaki, Refining of metallurgical silicon by directional solidification, Materials Science and Engineering B 176 (2011) 217-226.

DOI: 10.1016/j.mseb.2010.11.010

[8] Y. Su, Y. Liu, G. Liu, et al., Modeling of Temperature Field for Induction Skull Melting Process of Ti-47Ni-9Nb, Metallurgical and Materials Transactions A 32 (2001) 2895-2902.

DOI: 10.1007/s11661-001-1040-7

[9] A. Morita, H. Fukui, H. Tadano, S. Hayashi, J. Hasegawa, M. Niinomi, Alloying titanium and tantalum by cold crucible levitation melting (CCLM) furnace, Materials Science and Engineering A 280 (2000) 208-213.

DOI: 10.1016/s0921-5093(99)00668-1

[10] E. Ehret, Characterization of multicrystalline silicon: Comparison between conventional casting and electromagnetic casting processes, Solar Energy Materials and Solar Cells 53 (1998) 313-327.

DOI: 10.1016/s0927-0248(98)00022-1

[11] F. Durand, Electromagnetic continuous pulling process compared to current casting processes with respect to solidification characteristics, Solar Energy Materials & Solar Cells 72 (2002) 125-132.

DOI: 10.1016/s0927-0248(01)00157-x

[12] K. Morita, T. Miki. Thermodynamics of solar grade silicon refining. Intermetallics 11(2003) 1111-1117.

DOI: 10.1016/s0966-9795(03)00148-1
