Investigating the Effect of Shape Factor, Slurry Layers and Pouring Temperature in Precision Investment Casting

Abstract:

This paper aimed to investigate the effect of shape factor, slurry layers and pouring temperature in precision investment casting. Three controllable factors of the precision investment casting process (namely: shape factor, slurry layers (mold thickness) and pouring temperature) were studied at three levels each by Taguchis parametric approach and single-response optimization was conducted to identify the main factors controlling surface hardness, dimensional accuracy (Δd) and surface roughness (Ra). Castings were produced using aluminum (Al), mild steel (M.S.) and stainless steel (S.S) at recommended parameters through ceramic shell precision investment casting process. The micro structure analysis has been used to study the surface morphology. Analysis shows that for surface hardness, contribution of shape factor, slurry layers and pouring temperature is 0.07%, 0.70% and 99% respectively. As regards to surface roughness, contribution of shape factor, slurry layers and pouring temperature is 1.14%, 16.80% and 81.90% respectively. Further for Δd contribution of shape factor, slurry layers and pouring temperature is 1.53%, 22.47% and 72.88% respectively. Confirmation experiments were conducted at an optimal condition showed that the surface hardness, Δd and Ra of the precision investment casting were improved significantly.

• Periodical: Materials Science Forum (Volume 751)
• Pages: 35-44
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.751.35
• Online since: March 2013
• Authors: Rupinder Singh, Jagdeep Singh
• Keywords: Pouring Temperature, Precision Investing Casting, Shape Factor, Slurry Layer, Taguchi Method

References

[1] John, Olinger and Hines (1990), Computer-aided development of an investment casting process, Jounrals of Material Science, Vol. 45, pp.29-32.

[2] Hooker, Taylor and Leigh (1993), Nonaqueous slip casting of YBa2Cu3O7−x ceramics, Applied Super Conductivity Journals, Vol. 1, 7-9, 1303-1311.

DOI: 10.1016/0964-1807(93)90438-8

[3] Hung, Hou, Tsai and Huang (2003), Effect of Zirconia-Modified Magnesia Investment on the Casting of Pure Titanium, The Kaohsiung Journal of Medical Sciences, Vol. 19, 3, pp.121-125.

DOI: 10.1016/s1607-551x(09)70459-0

[4] P.Y. Jiann (2005), Fe evaluation of thermal property of mould wall material for investment casting and the effect of layers on the hardness of the casting product, University of Technology Malaysia.

[5] Zhang, Xiong and Xu (2006), Numerical methods to improve the computational efficiency of solidification simulation for the investment casting process, Journals of Material Processing Technology, Vol. 173, 1, pp.70-74.

DOI: 10.1016/j.jmatprotec.2005.09.030

[6] Rafique and Iqbal (2009), Determining the heat transfer of process phenomena during casting processes is an important parameter for measuring the overall performance, International Journal of Heat and Mass Transfer, Vol. 52, p.2132–2139.

DOI: 10.1016/j.ijheatmasstransfer.2008.11.007

[7] Dong, Bu, Dou and Zhang (2011), Determination of interfacial heat-transfer coefficient during investment-casting process of single-crystal blades, Journals of Material Processing Technology, Vol. 211, 12, pp.2123-1231.

DOI: 10.1016/j.jmatprotec.2011.07.012
