The New Materials Science Diffractometer RSD at CIAE

Abstract:

China Advanced Research Reactor (CARR) is a 60 MW tank-in-pool inverse neutron trap type reactor at CIAE. In order to use the non-destructive analytical techniques for phase specific residual stresses research, the new materials science diffractometer RSD was designed at CARR, which is one of the first commissioned instruments to meet the demand of industrial applications. The system comprises two types of monochromator, mosaic flat copper (220) and perfect double focusing silicon (311). The take-off angle of monochromator could change continuously from 41 to 109 degree. Therefore the neutron wavelength varies from 0.895 and 2.666 angstrom. The detector is a one dimension position sensitive detector. Various affiliated equipments enable it to do texture and tensional experiments. The best resolution could reach 0.2% using double focusing Si (311) monochromator. When RSD is available for routine operation, some research work in the field of nuclear industrial and aviatic engineering materials will be carried out using the beam of CARR.

You might also be interested in these eBooks

Mechanical Stress Evaluation by Neutrons and Synchrotron Radiation VII

View Preview

Info:

Periodical:

Materials Science Forum (Volume 777)

Pages:

161-164

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.777.161

Citation:

Cite this paper

Online since:

February 2014

Authors:

Jun Hong Li, Yun Tao Liu, Jian Bo Gao, Rui Hu, Rong Deng Liu, Shuo Sun, Ji Zhou Li, Dong Feng Chen

Keywords:

Double Focusing Monochromator, Neutron Diffraction, Position Sensitive Detector, Residual Stress

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D.F. Chen, Y.T. Liu, C. Gou, C.T. Ye: "Development of neutron scattering on 60MW research reactor in CIAE", Physica B (2006). 385–386 , 966–967

DOI: 10.1016/j.physb.2006.05.284

Google Scholar

[2] P.C. Brand, H.J. Prask, T.Gnaeupel-Herold: "Residual stress measurements at the NIST reactor", Physica B (1998). 241–243 , 1244–1245

DOI: 10.1016/s0921-4526(97)00837-5

Google Scholar

[3] M. Hofmann, R. Schneider, G.A. Seidl, J. Rebelo-Kornmeier, R.C. Wimpory, U. Garbe, H.-G. Brokmeier: "The new materials science diffractometer STRESS-SPEC at FRM-II", Physica B (2006). 385–386 , 1035–1037

DOI: 10.1016/j.physb.2006.05.331

Google Scholar
