Designing and Fabrication of the VLD Edge Termination for 3.3 kV SiC SBD

Abstract:

Edge termination guaranteeing high breakdown voltage and robustness in its fabrication are required in SiC power devices. We newly employed the VLD edge termination for 3.3 kV-rated SiC SBDs, which was formed by Al ion implantation using a resist mask having a varying thickness. The breakdown voltage is recorded to be over 96% of the parallel-plane breakdown voltage, and the reverse bias characteristics are well accorded with the result of TCAD simulation.
