Computation of Wave Propagation in Damped Specimen for Damage Detection

Abstract:

Aim of a structural health monitoring system must be to collect sufficient information about the damage for appropriate remedial measures to be taken to ensure safety. The preliminary step in the process of damage assessment is locating the damage .One of the challenges faced by the structural health monitoring system is monitoring in-flight damages. Localization of in-flight damages or sudden impacts can be achieved by monitoring the acoustic emissions in real time mode. In this paper, an approach based on the employment of Piezo-electric transducer rosettes to locate the acoustic emission source in an aluminum plate is presented. Using the strain gage rosette concepts adapted for piezoelectric transducers, the wave strain principal angles are determined. When two rosettes are used, the intersection of the principal wave strain directions detected by the rosettes gives the wave source location. The method does not require the knowledge of wave velocity in the medium in contrast to the time of flight based location. Hence, this technique can be used in anisotropic or complex structures where the source localization using the conventional time of flight method is difficult. The principal strain angle using the voltage response of the transducers and the rosette principles are obtained and the co-ordinates of the wave source location are calculated using the co-ordinates of the centroids of the rosettes in MATLAB.According to the tests, the rosette piezo-transducer outperforms the single piezo elements to a degree justifying its complexity. The rosette piezo transducer provides more damage related information compared to single elements and hence the performance of the damage detection system can be significantly improved if rosettes are used.

• Periodical: Materials Science Forum (Volumes 783-786)
• Pages: 2296-2301
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.783-786.2296
• Online since: May 2014
• Authors: Veena Jawali*, Prakash Parasivamurthy, Ashwini Nagesh
• Keywords: Macro-Fiber Composite Sensors (MFC), Piezoelectric Transducer (PZT), Structural Health Monitoring (SHM)

References

[1] Bedworth, M. and O'Brien, J., The Omnibus model: a new model of data Fusion, DERA Malvern preprint, (1999).

[2] Charles R Farrar, and Keith Worden, Engineering Science and Applications Division, Los Alamos National Laboratory Los Alamos, USA, An Introduction to Structural health monitoring, Phil. Trans. R. Soc. A, Vol. 365, No. 1851, p.303.

DOI: 10.3934/jgm.2019010

[3] Charles R. Farrar, Gyuhae Park, David W. Allen and Mike D. Todd, Engineering Sciences and Applications, The Engineering Institute, Los Alamos National Laboratory, USA, Sensor network paradigms for structural health monitoring Structure. Control Health Monit. Vol. 13, p.210.

DOI: 10.1002/stc.125

[4] Daniel C. Betz, Graham Thursby, Brian Culshaw and Wieslaw J. Staszewski, Dynamics Research Group, Department of Mechanical Engineering University of Sheffield, UK, Structural Damage Location with Fiber Bragg Grating Rosettes and Lamb Waves Structural Health Monitoring, Vol. 6, No. 4, p.299.

DOI: 10.1177/1475921707081974

[5] Francesco Lanza di Scalea, Howard Matt, Ivan Bartoli, Ankit Srivastava, Gyuhae Park, Charles Farrar The fundamental response of piezoelectric guided-wave sensors and applications to damage and impact location Third European Workshop on Structural Health Monitoring July 5-7, 2006 Univ. Politecnica Madrid, Univ. Granada, Spain.

[6] Friedrich Moser, Laurence J. Jacobs, JianminQu Modeling elastic wave propagation in waveguides with the finite element method, NDT&E International 32 (1999) 225–234.

DOI: 10.1016/s0963-8695(98)00045-0

[7] Grzegorz Kawiecki and Stephen Jesse, Department of Mechanical and Aerospace, The University of Tennessee, USA, Rosette piezotransducers for damage detection, Smart Mater. Struct., Vol. 11, p.196–201, (2002).

DOI: 10.1088/0964-1726/11/2/302

[8] Henry A. Sodano, Gyuhae Park, Daniel J. Inman, Center for Intelligent Material Systems and Structures, Virginia Polytechnic Institute and State University, USA, An investigation into the performance of macro-fiber composites for sensing and structural vibration applications, Mechanical Systems and Signal Processing. Vol. 18, p.683.

DOI: 10.1016/s0888-3270(03)00081-5

[9] Henry A. Sodano Macro-Fiber Composites for Sensing, Actuation and Power Generation, Paper presented to Virginia Polytechnic Institute and State University.

[10] HoonSohn, Charles R. Farrar, Francois M. Hemez Devin, D. Shunk, Daniel, W Stinemates, and Brett R. Nadler, Los Alamos National Laboratory Report, LA-13976-MS, A Review of Structural Health Monitoring Literature: 1996–2001, (2003).

[11] Howard M Mattand Francesco Lanza di Scalea, Department of Structural Engineering, University of California, Macro-fiber composite piezoelectric rosettes for acoustic source location in complex structures, Smart Material Structure, Vol. 16, pp.1489-1499.

DOI: 10.1088/0964-1726/16/4/064

[12] Howard M. Matt Structural Diagnostics of CFRP Composite Aircraft Components by Ultrasonic Guided Waves and Built-In Piezoelectric Transducers (dissertation, LA-14319-T Paper Issued: February 2007) University of California, San Diego.

DOI: 10.2172/899976
