Magneto-Dielectric Properties of Fe₃O₄/TiO₂/PTFE Composites and Antenna Simulation

Abstract:

In this paper, a novel composite of magneto-dielectric mixture Fe₃O₄/TiO₂ filled polymer PTFE was synthesized for a compact antenna application. Magnetic permeability, dielectric permittivity and related loss were measured and optimized. A planar patch antenna performance based on these composites with a center frequency at 1 GHz was simulated. The simulated antenna performances such as impedance bandwidth and radiation efficiency indicated that the antenna fabricated by this proposed composite could exhibit a better electrical property than that of conventional antenna printed on dielectric material.

• Periodical: Materials Science Forum (Volume 787)
• Pages: 352-356
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.787.352
• Online since: April 2014
• Authors: Zhi Hong Cheng*, Feng Zhang, An Ping Huang, Zhi Song Xiao
• Keywords: Composite, Magneto-Dielectric, Patch Antenna, PTFE

References

[1] H.Mosallaei, K.Sarabandi, Magneto-dielectrics in electromagnetics: Concept and applications, IEEE Trans. Antennas Propag. 52(2004), p.1558

DOI: 10.1109/tap.2004.829413

[2] J.Juuti, M.Teirikangas, K. Sonoda, H.Jantunen, Thermoplastic 0–3 ceramic–polymer composites with adjustable magnetic and dielectric characteristics for radio frequency applications, Int. J. Appl. Ceram.Tec. 7(2010), p.452

DOI: 10.1111/j.1744-7402.2010.02493.x

[3] A. Thakur, A. Chevalier, J.L. Mattei, P. Queffélec, Low-loss spinel nanoferrite with matching permeability and permittivity in the ultrahigh frequency range, J. Appl. Phys. 108(2010), p.014301

DOI: 10.1063/1.3455875

[4] R.V. Petrov, A.S. Tatarenko, G. Srinivasan, J.V. Mantese, Antenna miniaturization with ferrite ferroelectric composites, Microw Opt Techn Let. 50(2008), p.3154.

DOI: 10.1002/mop.23939

[5] B.W. Li, Y. Shen, Z.X. Yue, and C.W. Nan, Influence of particle size on electromagnetic behavior and microwave absorption properties of Z-type Ba-ferrite/polymer composites, J. Appl. Phys. 99(2006), p.123909

DOI: 10.1016/j.jmmm.2007.01.017

[6] H. Yang, H. Wang, F. Xiang, X. Yao, Multifunctional SrTiO3/NiZn Ferrite/POE Composites with Eletromagnetic and Flexible Properties for RF Applications, J. Electroceram, 22(2009), p.221

DOI: 10.1007/s10832-007-9368-z

[7] R.B. Yang, W.F. Liang, and C.K. Lin, Electromagnetic characteristics of manganese oxide-coated Fe3O4 nanoparticles at 2-18 GHz, J. Appl. Phys. 109(2011), p. 07D722

DOI: 10.1063/1.3545810

[8] R.C. Hansen, M. Burke, Antennas with magneto-dielectrics, Microwave Opt. Tech. Lett. 26(2000), p.75

[9] P.M. Ikonen, K.N. Rozanov, A.V. Osipov, P. Alitalo, S.A. Tretyakov, Magnetodielectric substrate in antenna miniaturization: Potential and limitations. IEEE Trans. Antennas. 54(2006), p.3391

DOI: 10.1109/tap.2006.884303

[10] K. Buell, H. Mosallaei, K. Sarabandi, A substrate for small patch antennas providing tunable miniaturization factors, IEEE Trans. Microwave Theory Tech. 54 (2006), p.135

DOI: 10.1109/tmtt.2005.860329

[11] K.Borah, N.S. Bhattacharyya, Magnetodielectric composite with ferrite inclusions as substrates for microstrip patch antennas at microwave frequencies, Composites Part B. 43 (2012), p.1309

DOI: 10.1016/j.compositesb.2011.11.067
