The Influence of Stress and Heat on the Transformation Behaviour of NiTi for Actuator Applications in Extruded Aluminium Matrix Composites

Abstract:

The integration of functions in lightweight structures features great potential for future applications in diagnosis and control. The combination of shape memory wires or ribbons made of NiTi embedded in aluminium and manufactured by composite extrusion offers the possibility to produce a composite actuator material in a single production step. The extrusion process allows a wide range of shapes and provides higher versatility than actuators made of bi-metals. The transformation temperature of NiTi varies depending on the composition of the alloy, between -100 °C and 100 °C. However, NiTi can also transform stress-induced. In the designated application, a force is applied via the interface onto the matrix material to deform it. Due to the resulting stress, the transformation temperature rises to temperatures higher than those of the unloaded material. Furthermore the production of composite extrusions leads to a significant heat input on the shape memory alloys followed by another increase of the transformation temperature.Therefore it is essential to reproduce the heat treatment and the stress-induced transformation to predict the transformation temperature in the resulting composite influenced by the interface. For that purpose, the wire gets annealed in a furnace with different durations at a temperature similar to that of the bar extrusion process. After this, the transformation temperatures can be observed at various stresses to evaluate their applicability for aluminium composite actuators.

• Periodical: Materials Science Forum (Volumes 825-826)
• Pages: 205-212
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.825-826.205
• Online since: July 2015
• Authors: Pascal Pinter*, Andreas Reeb, Kay André Weidenmann
• Keywords: Aluminium, Bar Extrusion, NiTi, Shape Memory Alloy

References

[1] C. Dahnke, D. Pietzka, M. Haase, A.E. Tekkaya, Extending the Flexibility in the Composite Extrusion Process, Procedia CIRP 18 (2014) 33-38.

DOI: 10.1016/j.procir.2014.06.103

[2] M. Schwane, C. Dahnke, M. Haase, N. Ben Khalifa, A.E. Tekkaya, Composite Hot Extrusion of Functional Elements, AMR 1018 (2014) 223-228.

DOI: 10.4028/www.scientific.net/amr.1018.223

[3] A. R. Pelton, J. Dicello, S. Miyazaki, Optimisation of processing and properties of medical grade Nitinol wire, Minim Invasive Ther Allied Technol 9 (2000) 107-118.

DOI: 10.3109/13645700009063057

[4] J. Khalil-Allafi, A. Dlouhy, G. Eggeler, Ni4Ti3-precipitation during aging of NiTi shape memory alloys and its influence on martensitic phase transformations, Acta Materialia 50 (2002) 4255-4274.

DOI: 10.1016/s1359-6454(02)00257-4

[5] A. Ghabchi, J. Khalil-Allafi, X.W. Liu, O. Söderberg, E. Turunen, S. -P. Hannula, Effect of aging and solution annealing on transformation and deformation mechanism of super-elastic Ni50. 9%- Ti alloy in nano- scale, in: ESOMAT 2009 - 8th European Symposium on Martensitic Transformations.

DOI: 10.1051/esomat/200902009

[6] D.C. Lagoudas, Shape memory alloys: Modeling and engineering applications, Springer, New York, London, (2008).

[7] J. Uchil, Shape memory alloys-characterization techniques, Pramana 58 (2002) 1131-1139.

DOI: 10.1007/s12043-002-0229-7

[8] J.A. Shaw, C.B. Churchill, M.A. Iadicola, Tips and Tricks for characterizing shape memory alloy wire: Part 1-Differential Scanning Caliometry and basic Phenomena, Experimental Techniques 32 (2008) 55-62.

DOI: 10.1111/j.1747-1567.2008.00410.x

[9] C.B. Churchill, J.A. Shaw, M.A. Iadicola, Tips and Tricks for characterizing shape memory alloy wire: Part 1-Fundamental isothermal Responses, Experimental Techniques 33 (2009) 51-62.

DOI: 10.1111/j.1747-1567.2008.00460.x

[10] J. Frenzel, E.P. George, A. Dlouhy, C. Somsen, M. -X. Wagner, G. Eggeler, Influence of Ni on martensitic phase transformations in NiTi shape memory alloys, Acta Materialia 58 (2010) 3444-3458.

DOI: 10.1016/j.actamat.2010.02.019

[11] K.L. Ng, Q.P. Sun, Stress-induced phase transformation and detwinning in NiTi polycrystalline shape memory alloy tubes, Mechanics of Materials 38 (2006) 41-56.

DOI: 10.1016/j.mechmat.2005.05.008

[12] Gallardo Fuentes, J. M., P. Gümpel, J. Strittmatter, Phase Change Behavior of Nitinol Shape Memory Alloys, Adv. Eng. Mater. 4 (2002) 437-452.

DOI: 10.1002/1527-2648(20020717)4:7<437::aid-adem437>3.0.co;2-8

[13] W. Voigt, Ueber die Beziehung zwischen den beiden Elasticitätsconstanten isotroper Körper, Ann. Phys. 274 (1889) 573-587.

DOI: 10.1002/andp.18892741206

[14] A. Kelly, G.J. Davies, THE PRINCIPLES OF THE FIBRE REINFORCEMENT OF METALS, Metallurgical Reviews 10 (1965) 1-77.

DOI: 10.1179/mtlr.1965.10.1.1
