Analyses of Boundary Conditions for Process Integration of Sensor Elements in Complex Fibre-Reinforced Thermoplastic Spacer Structures

Abstract:

The application of hybrid yarns and their further processing to textile preforms enforce adapted manufacturing processes. Furthermore, a consolidation of cross-section varying parts requires an adapted mold and core system for a reproducible production process. Similarly, the application of hybrid yarns facilitates low consolidation pressures and thus favors the integration of electronic components in fibre-reinforced thermoplastic parts. In this paper, the analyses of the boundary conditions for a process integration of sensor elements in complex fibre-reinforced spacer structures are presented.

• Periodical: Materials Science Forum (Volumes 825-826)
• Pages: 533-540
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.825-826.533
• Online since: July 2015
• Authors: Teresa Möbius*, Michael Krahl, Martin Helwig, Frank Adam, Niels Modler, Eric Starke, Sebastian Sauer, Wolf Joachim Fischer
• Keywords: Fibre-Reinforced Thermoplastic, Hybrid Yarn, Sensor Node

References

[1] B.D. Choi, Entwicklung von Commingling-Hybridgarnen für langfaserverstärkte thermoplastische Verbundwerkstoffe, Dissertation, Technische Universität Dresden, Germany, (2005).

[2] C. Herzberg, N. Zhao, H. Rödel, Beanspruchungsgerechte Abstandsstrukturen für komplexe Leichtbauanwendungen durch funktionsgerechte Nähtechnik, in W. Krenkel (Ed. ), Verbundwerkstoffe, Weinheim, 2009, pp.440-447.

DOI: 10.1002/9783527627110.ch62

[3] K. Großmann, A. Mühl, M. Löser, C. Cherif, G. Hoffmann, A. R. Torun, New solutions for the manufacturing of spacer preforms for thermoplastic textile-reinforced lightweight structures, Production Engineering. Res. and Devel. 4 (2010) 589-597.

DOI: 10.1007/s11740-010-0267-9

[4] C. Herzberg, A. Kempe, H. Rödel, Nähtechnische Fertigung von gekrümmten, textilen 3D Halbzeugen für den Leichtbau, Verbundwerkstoffe, in W. Krenkel (Ed. ), Verbundwerkstoffe, Weinheim, 2011, pp.245-250.

[5] C. Herzberg, M. Waldmann, H. Rödel and L. Song, DE Patent DE 10 2008 000722 A1. (2013).

[6] W. Hufenbach, F. Adam, J. Beyer, M. Zichner, M. Krahl, S. Lin, U. Hanke, Development of an adapted process technology for complex thermoplastic lightweight structures based on hybrid yarns, Proceedings of 17th International Conference on Composite Materials (2009).

[7] M. Abounaim, G. Hoffmann, O. Diestel, C. Cherif, Thermoplastic composite from innovative flat knitted 3D multi-layer spacer fabric using hybrid yarn and the study of 2D mechanical properties, Composites Science and Technology 70 (2010) 363-370.

DOI: 10.1016/j.compscitech.2009.11.008

[8] W. Hufenbach, F. Adam, M. Krahl, K. -H. Modler, U. Hanke, K. Großmann, S. Rehn, Novel manufacturing process for complex thermoplastic lightweight structures using adapted consolidation kinematics, Proceedings of International Conference on Manufacturing of Advanced Composites, Belfast (2011).

[9] A. Javidinejad, S. P. Joshi, Autoclave reliability of MEMS pressure and temperature sensors embedded in carbon fiber composites, J. of Electronic Packaging 123 (2001) 79-82.

DOI: 10.1115/1.1322563

[10] A. Kunadt, A. Heinig, E. Starke, G. Pfeifer, C. Cherif, W. -J. Fischer, Design and Properties of a Sensor Network Embedded in thin Fiber-Reinforced Composites, IEEE Sensors Conference (2010) 673-677.

DOI: 10.1109/icsens.2010.5690085
