Wetting Behavior and Interface Characteristic of Ti_32.8Zr_30.2Ni_5.3Cu₉Be_22.7/Ti6Al4V

Abstract:

The wetting behavior and the interaction at the liquid-solid interface are significant in preparation of metallic glass composite. In this paper, the wetting behavior and the interfacial interaction between Ti_32.8Zr_30.2Ni_5.3Cu₉Be_22.7 (denoted as ZT3) bulk metallic glass (BMG) alloy melt and Ti6Al4V (denoted as TC4) substrate at different temperatures were investigated using sessile drop method. The results show that ZT3 alloy melt wetted the substrate well. With the increase of temperature, the droplet spread out rapidly and then came to equilibrium gradually. The equilibrium contact angle under 1273 K stabilized at about 15°. Dendrite phase generated at the interface during the wetting progress. The composition of the interface product transformed from Ti_69.8Zr_24.2Al_2.2V₁Cu_2.8 to Ti_73.6Zr_15.3Al₅V_2.7Cu_2.6Ni_0.8 with the temperature rising from 973 K to 1273 K. Meanwhile, the dissolution of the TC4 substrate increased with increasing the temperature.

• Periodical: Materials Science Forum (Volume 849)
• Pages: 385-390
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.849.385
• Online since: March 2016
• Authors: Ding Ming Liu, Zheng Wang Zhu, Zheng Kun Li, Hua Meng Fu, Hong Li, Ai Min Wang, Hong Wei Zhang, Haifeng Zhang*, Zhuang Qi Hu
• Keywords: BMG, Contact Angle, Interface, Ti6Al4V, Wetting

References

[1] A. Inoue, A. Takeuchi, Recent development and application products of bulk glassy alloys, Acta Mater. 59 (2011) 2243-2267.

DOI: 10.1016/j.actamat.2010.11.027

[2] A. L. Greer, Metallic glasses .. on the threshold, Mater Today. 12 (2009) 14-22.

[3] W. H. Wang, The elastic properties, elastic models and elastic perspectives of metallic glasses, Prog Mater Sci. 57 (2012) 487-656.

DOI: 10.1016/j.pmatsci.2011.07.001

[4] A. L. Greer, Y. Q. Cheng, E. Ma, Shear bands in metallic glasses, Mater Sci Eng R. 74 (2013) 71-132.

[5] H. F. Zhang, H. Li, A. M. Wang, H. M. Fu, B. Z. Ding, Z. Q. Hu, Synthesis and characteristics of 80 vol. % tungsten (W) fibre/Zr based metallic glass composite, Intermetallics. 17 (2009) 1070-1077.

DOI: 10.1016/j.intermet.2009.05.011

[6] Z. K. Li, H. M. Fu, P. F. Sha, Z. W. Zhu, A. M. Wang, H. Li, H. W. Zhang, H. F. Zhang, Z. Q. Hu, Atomic interaction mechanism for designing the interface of W/Zr-based bulk metallic glass composites, Sci Rep. 5 (2015) 1-6.

DOI: 10.1038/srep08967

[7] R. D. Conner, R. B. Dandliker, W. L. Johnson, Mechanical properties of tungsten and steel fiber reinforced Zr41. 25Ti13. 75Cu12. 5Ni10Be22. 5 metallic glass matrix composites, Acta Mater. 46 (1998) 6089-6102.

DOI: 10.1016/s1359-6454(98)00275-4

[8] C. C. Hays, C. P. Kim, W. L. Johnson, Microstructure controlled shear band pattern formation and enhanced plasticity of bulk metallic glasses containing in situ formed ductile phase dendrite dispersions, Phys Rev Lett. 84 (2000) 2901-2904.

DOI: 10.1103/physrevlett.84.2901

[9] D. C. Hofmann, J. Y. Suh, A. Wiest, G. Duan, M. L. Lind, M. D. Demetriou, W. L. Johnson, Designing metallic glass matrix composites with high toughness and tensile ductility, Nature. 451 (2008) 1085-U1083.

DOI: 10.1038/nature06598

[10] J. W. Qiao, In-situ Dendrite/Metallic Glass Matrix Composites: A Review, J Mater Sci Technol. 29 (2013) 685-701.

[11] M. Tang, Z. Zhu, H. Fu, A. Wang, H. Li, H. Zhang, G. Ma, H. Zhang,Z. Hu, Ti-based amorphous composites with quantitatively controlled in-situ formation of dendrites, Acta Metall Sinica. 48 (2013) 861-866.

DOI: 10.3724/sp.j.1037.2012.00198

[12] M. Q. Tang, H. F. Zhang, Z. W. Zhu, H. M. Fu, A. M. Wang, H. Li,Z. Q. Hu, TiZr-base Bulk Metallic Glass with over 50 mm in diameter, J Mater Sci Technol. 26 (2010) 481-486.

DOI: 10.1016/s1005-0302(10)60077-1

[13] G. Kumar, K. N. Prabhu, Review of non-reactive and reactive wetting of liquids on surfaces, Adv Colloid Interface. 133 (2007) 61-89.

DOI: 10.1016/j.cis.2007.04.009

[14] Z. K. Li, G. F. Ma, H. M. Fu, P. F. Sha, B. Zhang, Z. W. Zhu, A. M. Wang, H. Li, H. W. Zhang, H. F. Zhang, Z. Q. Hu, The spreading kinetics and precursor film characteristics of Zr-based alloy melt on W substrate, Mater Lett. 98 (2013) 98-101.

DOI: 10.1016/j.matlet.2013.02.005

[15] N. Eustathopoulos, Progress in understanding and modeling reactive wetting of metals on ceramics, Curr Opin Solid St M. 9 (2005) 152-160.

[16] E. Saiz, R. M. Cannon,A. P. Tomsia: High-temperature wetting and the work of adhesion in metal/oxide systems, Ann. Rev. Mater. Res. 38 (2008) 197-226.

DOI: 10.1146/annurev.matsci.38.060407.132443

[17] G Lütjering, JC Williams, Titanium: engineering materials and processes, second ed, Manchester, UK: Springer; (2007).
