The Investigation of Electrical Properties for Mica/Epoxy Insulation Stator Bars during the Thermal Cycle Aging Test

Abstract:

As the pumped storage stations played an important role in peak and frequency modulation, the reversible pump turbines were often subjected to rapid temperature transitions. In this research, considering the complexity operation condition of these kinds of motors, a novel thermal cycle aging platform was designed and the thermal cycling aging test was conducted on epoxy/mica insulation stator bars. Dielectric loss angle tangent (tanδ), capacitor (C), leakage current (I) and other electrical properties of stator bars were investigated at different aging time. The results showed that, tanδ and C of the stator bars increased with increasing aging time, while I (current) did not change significantly.

• Periodical: Materials Science Forum (Volume 868)
• Pages: 50-55
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.868.50
• Online since: August 2016
• Authors: Liang Liang Nie, Zhi Wei Li, Shi Di Tao, Zhao Liu, Hai Jin, Nai Kui Gao*
• Keywords: Capacitor, Dielectric Loss Tangent, Leakage Current, Stator Bar, Thermal Cycle Aging

References

[1] J. Y. Shi. Study on life prediction of class F insulation for stator coils of large turbo-generators[J]. J. Chin. Soc. Power Eng., 33 (2013) 507-516.

[2] M. Sumislawska, K.N. Gyftakis, D.F. Kavanagh, et al. The impact of thermal degradation on electrical machine winding insulation. Proceeding of 2015 IEEE 10th International Symposium on Diagnostics for Electrical Machines, Power Electronics and Drives, Guarda, Portugal, 1-4 Sept. 2015: 232-238.

DOI: 10.1109/demped.2015.7303695

[3] IEEE 1310-2012, IEEE Recommended Practice for Thermal Cycle Testing of Form-Wound Stator Bars and Coils for Large Rotating Machines, (2012).

DOI: 10.1109/ieeestd.2012.6204190

[4] C. Fölting and F. Jenau. Implementation and analysis of multi-factor aging tests on the winding insulation of original sized generator stator bars used in large rotating machines, Proceeding of 2014 International Conference on High Voltage Engineering and Application, Poznan, Poland, 8-11 Sept. 2014, 4 pp.

DOI: 10.1109/ichve.2014.7035396

[5] C. Pan, Y. P. Meng, K. Wu. Variation of surface charge distribution in the process of PD degradation[C]. Proceedings of 2011 International Symposium on Electrical Insulating Materials, Kyoto, Japan, 6-10 Sept. 2011, 117-120.

DOI: 10.1109/iseim.2011.6826363

[6] G.C. Stone, M.K.W. Stranges, D.G. Dunn. Common Questions on Partial Discharge Testing: A Review of Recent Developments in IEEE and IEC Standards for Offline and Online Testing of Motor and Generator Stator Windings[J]. IEEE Ind. Appl. Mag., 22 (2016).

DOI: 10.1109/mias.2015.2458337
