Enhanced Electrical Resistivity and Soft Magnetic Properties in Ca-Doped Fe-B-Cu Alloy Ribbons

Abstract:

Fe_83.5B₁₅Cu_1.5Ca_x (x= 0.04, 0.07, 0.1 and 0.13) alloy ribbons were fabricated by melt spinning. The effects of Ca addition on electrical resistivity and soft magnetic properties were investigated. The results show that with increasing Ca content from 0.04 to 0.13 the electrical resistivity monotonously increases from 0.51 μΩ·m to 0.99 μΩ·m while the core loss reduced by 39% and 28% at 10 kHz and 20kHz under an applied magnetic field of 200 mT, respectively. After annealing at 420°C for 10min, sample with x=0.13 obtains the peak saturation induction density (B_s) of 1.82 T and coercive force (H_c) of 18 A/m. Especially, the core loss of sample x=0.13 decreased by 13% and 34% than that of x= 0.04 at 200 kHz under an applied magnetic field of 25 mT and 50 mT respectively. Therefore, the soft magnetic properties and core loss can be tuned by addition of Ca in Fe-B-Cu alloy ribbons.

• Periodical: Materials Science Forum (Volume 873)
• Pages: 23-27
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.873.23
• Online since: September 2016
• Authors: Zhi Gang Zheng*, J.S. Zhang, H.Y. Yu, B. Li, D.C. Zeng, F.M. Xiao, T. Sun, R.H. Tang
• Keywords: Core Loss, Electrical Resistivity, Melt Spinning, Saturation Flux Density

References

[1] Y. Yoshizawa, S. Oguma, K. Yamauchi. New Fe-based soft magnetic alloys composed of ultrafine grain strcture. Journal of Applied Physics, 1988, 64: 6044-6046.

DOI: 10.1063/1.342149

[2] K. Suzuki, A. Makino, N. Kataoka, et al. High saturation magnetization and soft magnetic properties of bcc-Fe-Zr-B and Fe-Zr-B-M (M= Transition Metal) alloys with Nanoscale Grain Size. Materials Transactions, 1991, 32: 93-102.

DOI: 10.2320/matertrans1989.32.93

[3] Y. M. Chen, T. Ohkubo, M. Ohta, et al. Three-dimensional atom probe study of Fe-B-based nanocrystalline soft magnetic materials. Acta Materialia, 2009, 57: 4463-4472.

DOI: 10.1016/j.actamat.2009.06.008

[4] M. Ohta, Y. Yoshizawa. Effect of Heating Rate on Soft Magnetic Properties in Nanocrystalline Fe80. 5Cu1. 5Si4B14 and Fe82Cu1Nb1Si4B12 Alloys. Applied Physics Express, 2009, 023005: 1-3.

[5] Z. Z. Tai, B. Y. Huang, W. S. Liu. Large electrical resistivity and high saturation magnetization nanocrystalline Fe86B13Cu1 alloy prepared by hot isothermal pressing. Materials Letters, 2010, 64: 733-735.

DOI: 10.1016/j.matlet.2010.01.004

[6] J. S. Tang, D. P. Hu, Z. Z. Tai, et al. Microstructures and soft magnetic properties of nanocrystalline Fe86B13Cu1 alloy annealed by hot isothermal pressing. Journal of Alloys and Compounds, 2010, 493: 134-136.

DOI: 10.1016/j.jallcom.2009.12.139

[7] M. R. Kim, S. I. Kim, K. S. Kim, et al. Effect of Ca Addition on Soft Magnetic Properties of Nanocrystalline Fe-Based Alloy Ribbons. Metals and Materials International, 2012, 18: 185-188.

DOI: 10.1007/s12540-012-0024-z

[8] Nippon Steel Corporation, Catalog of the Non-orientated Electrical steel sheets, Available: http: /www. nsc. co. jp/en/product/sheet/pdf/EXE319. pdf.

[9] T. Kubota, A. Makino, A. Inoue. Low core loss of Fe85Si2B8P4Cu1 nanocrystalline alloys with high Bs and B800. Journal of Alloys and Compounds, 2011, 509S: 416-419.

DOI: 10.1016/j.jallcom.2010.11.012

[10] M. Ohta, Y. Yoshizawa. Magnetic properties of high Bs Fe-Cu-Si-B nanocrystalline soft magnetic alloys. Journal of Magnetism and Magnetic Materials, 2008, 320: e750-e753.

DOI: 10.1016/j.jmmm.2008.04.064

[11] C.R. Hendricks, V.W.R. Amarakoon, D. Sullivan. Processing of manganese zinc ferrites for high-frequency switch-mode power supplies. American Ceramic Society Bulletin, 1991, 70: 817–823.

[12] H. Shokrollahi, K. Janghorban. Soft magnetic composite materials (SMCs). Journal of Materials Processing Technology, 2007, 189: 1-12.

DOI: 10.1016/j.jmatprotec.2007.02.034
