Temperature Field Evolution during Flash Butt Welding of Railway Rails

Abstract:

Flash butt welding (FBW) of railway rails was investigated in this work. For this purpose samples of R260 rail steel and 60E1 profile were instrumented and subsequently welded on a Schlatter GAA 100 welding machine under industrial conditions. The intention is to gain in depth process knowledge by more accurately depicting thermal cycles for an entire welding sequence in the immediate proximity of the weld as well as in the heat affected zone (HAZ). A detailed characterization of the single stages of the heat up phase of the process is important. Additionally, the secondary welding voltage was measured simultaneously during the experiments to characterize the transient heat input. Moreover, these data were used in the analysis of the temperature signals to better cope with electrical interferences. Additionally, a finite element (FE) model of this FBW process was developed in the present work. Its implementation and solution is realized with the help of ESI’s FE-software SYSWELD. A strong coupled thermo-electrokinetical and metallurgical calculation routine was used. The model comprises the transition resistance at the welding surfaces as the main heat source to the process. Temperature dependent material properties and a corresponding metallurgical model based on an experimental CCT diagram of the rail steel R350HT are implemented in the simulation as well.

• Periodical: Materials Science Forum (Volume 879)
• Pages: 2088-2093
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.2088
• Online since: November 2016
• Authors: Leonhard Weingrill*, Jörg Krutzler, Norbert Enzinger
• Keywords: Experimental Validation, Flash Butt Welding, Numerical Simulation, Pearlite, Rail

References

[1] J. Keichel and R. Gehrmann, Neues Thermit-Schweißverfahren SkV-Elite, Elektro Thermit GmbH & Co KG Halle Germany, EI-Eisenbahingenieur, p.50–53, Sep-(2008).

[2] A. Zlatnik, Welding Competence Center voestalpine Schienen GmbH. Donawitz AUSTRIA, (2015).

[3] G. Girsch, J. Keichel, R. Gehrmann, A. Zlatnik, and N. Frank, Advanced Rail Steels for Heavy Haul Application-Track Performance and Weldability, 9th Int. Heavy Haul Conf., p.171–178, (2009).

[4] EN 13674-1: 2011 Bahnanwendungen - Oberbau -Schienen Teil 1: Vignolschienen ab 46kg/m;, Österreichisches Normungsinstitut, (2011).

[5] S. Prohaska and J. Albert, Next-generation super-premium rail steels hit the tracks, " voestalpine Schienen GmbH, Austria, 2015. [Online]. Available: http: /www. railjournal. com/index. php/track/next-generation-super-premium-rail-steels-hit-the-tracks. html, channel=531.

[6] D. Embury, 8 - The formation of pearlite in steels, Phase Transform. Steels Fundam. Diffus. Transform., vol. 1, no. 1930, p.276–310, (2012).

DOI: 10.1533/9780857096104.2.276

[7] E. M. Taleff, J. J. Lewandowski, and B. Pourladian, Microstructure-property relationships in pearlitic eutectoid and hypereutectoid carbon steels, Jom, vol. 54, no. 7, p.25–30, (2002).

DOI: 10.1007/bf02700982

[8] F. G. Caballero, C. García De Andrés, and C. Capdevila, Characterization and morphological analysis of pearlite in a eutectoid steel, Mater. Charact., vol. 45, no. 2, p.111–116, (2000).

DOI: 10.1016/s1044-5803(00)00056-5

[9] M. D. G. M. da F. Gomes, L. H. de Almeida, L. C. F. C. Gomes, and I. Le May, Effects of Microstructural Parameters on the Mechanical Properties of Eutectoid Rail Steels, Mater. Charact., vol. 39, no. 97, p.1–14, (1997).

DOI: 10.1016/s1044-5803(97)00086-7

[10] K. M. Wu and H. K. D. H. Bhadeshia, Extremely fine pearlite by continuous cooling transformation, Scr. Mater., vol. 67, no. 1, p.53–56, (2012).

DOI: 10.1016/j.scriptamat.2012.03.019

[11] M. Maalekian, Friction Welding of Rails, PhD Th. Graz University of Technology, (2007).

[12] A. Skyttebol and B. L. Josefson, Numerical Simulation of Flash-Butt-Welding of Railway Rails, in Mathematical Modelling of Weld Phenomena 7, 2004, p.21.

[13] D. Tawfik, P. J. Mutton, and W. K. Chiu, Modifying residual stress levels in rail flash-butt welds using localised rapid post-weld heat treatment and accelerated cooling, Int. Heat Treat. Surf. Eng., vol. 2, no. 3–4, p.126–130, (2008).

DOI: 10.1179/174951508x429212

[14] Y. Li and F. Zhang, Numerical Simulation Of Flash Butt Welding Of High Manganese Steel Crossing With Carbon Steel Rail, Adv. Mater. Res., vol. 123–125, p.571–574, (2010).

DOI: 10.4028/www.scientific.net/amr.123-125.571

[15] X. -F. Xu, L. Liu, and G. Zji-Ke, Finite element analysis on the temperature field distribution of flash butt welding of rail, J. Shanghai Jiaotong Univ. China, vol. 42, no. 5, p.778–781, (2008).

[16] T. Kuroda and M. Shimada, Micro flash butt welding of super duplex stainless steel with Zr-based metallic glass insert, Vacuum, vol. 83, no. 1, p.153–156, (2008).

DOI: 10.1016/j.vacuum.2008.03.089
