Orientation Relations of Martensitic Transformations in FeMnCr Steels

Abstract:

The crystallographic orientation relations of phases forming during the martensitic transformation determine the properties of alloys. In TRIP/TWIP steels, the circumstances of thermomechanical treatment (e.g. temperature, deformation) define the forming of martensites of different origins. Due to the thermomechanical treatment, thermally induced martensite (ε_TH), strain induced martensite (ε_D) and α’ martensite phases are present in the samples besides the austenite. The proportion of martensites in the sample is defined by the parameters of treatment. The thermally and strain induced martensites which are simultaneously present in the alloy at room temperature can be differentiated by the orientation relations.The martensitic transformations were followed by different methods in FeMn alloys with different Cr content. The macroscopic crystallographic anisotropy was measured by X-ray diffraction method; the microscopic one was examined by EBSD. The cognition of phenomenon observed in the texture image in different scales helps determine the possible origin of martensites.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volume 885)

Pages:

165-170

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.885.165

Citation:

Cite this paper

Online since:

February 2017

Authors:

Erzsebet Nagy*, Márton Benke, Árpád Kovács, Valéria Mertinger

Keywords:

EBSD, Martensitic Transformation, Texture, TWIP Steel, X-Ray Diffraction

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] E. Bayraktar, F.A. Kalid, C. Le Vaillant, Deformation and fracture behavior of high manganese austenitic steel, J. Mater. Process. Technol. 147 (2004) 145-154.

Google Scholar

[2] Y. Dai, D. Tang, Z. Mi, J. Lü, Microstructure characteristics of an Fe-Mn-C TWIP steel after deformation, Int. J. Iron Steel Res. 17 (9) (2010) 53-59.

DOI: 10.1016/s1006-706x(10)60142-2

Google Scholar

[3] K.H. Kwon, B-C. Suh, S. Baik, Y-W. Kim, J-K. Choi, N.J. Kim, Deformation behaviour of duplex austenite and ε martensite high-Mn steel, Sci. Technol. Adv. Mater. 14 (2013) 014204 (8pp) Online at stacks. iop. org/STAM/14/014204.

DOI: 10.1088/1468-6996/14/1/014204

Google Scholar

[4] L. Remy, A. Pineau, Twinning and strain-induced F.C.C. - H.C.P. transformation in the Fe-Mn-Cr-C system, Mater. Sci. Eng. 28 (1977) 99-107.

DOI: 10.1016/0025-5416(77)90093-3

Google Scholar

[5] L. Bracke, K. Verbeken, L. Kestens, J. Penning, Microstructure and texture evolution during cold rolling and annealing of a high Mn TWIP steel, Acta Mater. 57 (2009) 1512-1524.

DOI: 10.1016/j.actamat.2008.11.036

Google Scholar

[6] L. Bracke, K. Verbeken, L. Kestens, Texture generation and implications in TWIP steels, Scripta Mater. 66 (2012) 1007-1011.

DOI: 10.1016/j.scriptamat.2012.02.048

Google Scholar

[7] D.P. Escobar, S.S. Ferreira de Dafé, D.B. Santos, Martensite reversion and texture formation in 17Mn-0. 06C TRIP/TWIP steel after hot cold rolling and annealing, J. Mater. Res. Technol. 4(2) (2015) 162-170.

DOI: 10.1016/j.jmrt.2014.10.004

Google Scholar

[8] K.M. Rahman, N.G. Jones, D. Dye, Micromechanics of twinning in TWIP steel, Mater. Sci. Eng. A 635 (2015) 133-142.

DOI: 10.1016/j.msea.2015.03.082

Google Scholar

[9] V. Mertinger, E. Nagy, M. Benke, F. Tranta, Characteristics of Martensitic Transformations Induced by Uni-axial Tensile Tests in a FeMnCr Steel, Mat. Sci. Forum 812 (2015) 161-166.

DOI: 10.4028/www.scientific.net/msf.812.161

Google Scholar
