Effect of Annealing Temperature on Microstructure and Properties of Ultra Purified Ferritic Stainless Steel Containing Copper

Abstract:

The effects of annealing temperature on microstructure, mechanical properties, formability, and texture evolution were analyzed in the article. The microstructure of the steel obtained through different annealing processes were investigated by means of transmission electron microscopy; The micro texture of steel was measured by using electron back scattering diffraction analysis; The relationship between Cu precipitates and matrix was analyzed by using the selected area diffraction technology. The results show that when annealing temperature was 700 ~ 850 °C, the yield strength and tensile strength first decreased slightly and then increased, while the elongation accordingly first increased then decreased slightly. The best mechanical property and formability were obtained at 800 °C. Cu precipitates reduced with the increase of annealing temperature and it accorded with K - S relationship with matrix. The grains near the {111} < 112 > orientation grew up selectively. The higher the temperature, the more the γ fiber texture content. But at higher temperature (850 °C), γ texture was damaged and the content was reduced.

• Periodical: Materials Science Forum (Volume 913)
• Pages: 270-276
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.913.270
• Online since: February 2018
• Authors: Hong Xiang Yin*, Yi Wu, Ai Min Zhao, Zheng Zhi Zhao, Qiu Qin Fu
• Keywords: Annealing Temperature, Cu Alloying, Cu Precipitates, Ferritic Stainless Steel, Texture

References

[1] X.Y. Zhang, X.B. Huang, L. Jiang, Y. Ma, A.L. Fan and B, Tang. Antibacterial property of Cu modified stainless steel by plasma surface alloying, Journal of Iron and Steel Research, International. 19 (2012) 75-79.

DOI: 10.1016/s1006-706x(12)60091-0

[2] Y. Dong, X. Li, L. Tian and H. Dong, Towards long-lasting antibacterial stainless steel surfaces by combining double glow plasma silvering with active screen plasma nitriding, Acta Biomaterialia. 7 (2011) 447-457.

DOI: 10.1016/j.actbio.2010.08.009

[3] C.F. Hung, C.Z. Wu, W.F. Lee, K.L. Ou, C.M. Liu and P.W, Peng The effect of nitrided layer on antibacterial properties for biomedical stainless steel, Physics Procedia. 32 (2012):914-919.

DOI: 10.1016/j.phpro.2012.03.656

[4] N. Li, Y. Ke, Cu ions dissolution from cu-bearing antibacterial stainless steel, J. Mater. Sci. Technol. 26 (2010) 941-944.

DOI: 10.1016/s1005-0302(10)60152-1

[5] M.Q. LV, S.H. Chen, J.S. Dong and Y. Ke, Pilot study about the killing bacteria process and mechanism of ferrite antibacterial stainless steel, Metallic Functional Materials. 12 (2005) 10-13.

[6] S.H. Chen, M.Q. LV, J.D. Zhang, J.S. Dong and Y. Ke, Microstructure and antibacterial properties of cu-contained and its antibacterial properties antibacterial stainless steel, Acta Metallurcica Sinica. 40 (2004) 314-318.

[7] Y. Ke, J.S. Dong, S.H. Chen and M.Q. LV, The craftwork performance and resistance to corrosion of the Cu-containing antibacterial stainless steels, Chinese Journal of Materials Research. 20 (2006) 523-527.

[8] N. Maruyama, M. Sugiyama, T. Hara and T. Hiroshi, Precipitation and phase transformation of copper particles in low alloy ferritic and martensitic steels, Material Transactions, JIM. 40 (1999) 268-277.

DOI: 10.2320/matertrans1989.40.268

[9] K. Osamura, H. Okuda, S. Ochial, M. Takashima, K. Asano, M. Furusaka, K. Kishida, and F.Kurosawa, Precipitation hardening in Fe-Cu binary and quatenary alloys, ISIJ International. 34 (1994) 359-365.

DOI: 10.2355/isijinternational.34.359

[10] M. Morita, K. Sato and Y. Hosoya, Effects of Cu and Ti-precipitates on recrystallization texture of Cu-precipitation hardening ultra low carbon cold-rolled steel sheet, Tetsu-to-hagané. 80 (1994) 48-53.

DOI: 10.2355/tetsutohagane1955.80.1_48

[11] F. Gao F, Z.Y. Liu, H.T. Liu, and G.D. Wang, Texture evolution and formability under different hot rolling conditions in ultra purified 17%Cr ferritic stainless steels, Materials Characterization. 75 (2013) 93-100.

DOI: 10.1016/j.matchar.2012.09.006
