Numerical Modeling of Thermal Stress State of "Shell Mold-Casting" System with Phase Change when Inverstment Casting

Abstract:

This work summarizes and generalizes the results of long term researches of mathematic modeling of stress-strain state (SSS) of shell molds (SM) considering their morphological structure and types of hydromechanical and temperature impacts on them. A problem for determination of SSS of multilayer SM with internal porous layer during filling this mold with melt and mold hardening considering the phase changes was set and solved. At the same time the calculation methodology described in the early works of authors, namely constitutive equation system, numerical method, numerical scheme and solution algorithm was used. The results of numerical solution of the problem, namely diagrams of stresses arising in the SM during casting hardening are given here.

• Periodical: Materials Science Forum (Volume 945)
• Pages: 791-795
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.945.791
• Online since: February 2019
• Authors: V.I. Odinokov, A.V. Sviridov, E.A. Dmitriev
• Keywords: Hardening, Numerical Modeling, Porous Layer, Shell Mold, Steel Casting, Stress, Stress-Strain State

References

[1] A.I. Evstigneev, V.I. Odinokov, A.V. Sviridov, E.A. Dmitriev, V.V. Petrov, Theoretical prediction of crack formation in axisymmetric multilayer shell molds, Materials Science Forum. 857 (2016) 573-577.

DOI: 10.4028/www.scientific.net/msf.857.573

[2] A.I. Evstigneev, V.I. Odinokov, A.V. Sviridov, E.A. Dmitriev, V.V. Petrov. Mathematical modeling of stress-strain state of multilayer shell molds. Materials Science Forum. 857 (2016) 565-572.

DOI: 10.4028/www.scientific.net/msf.857.565

[3] A.V. Sviridov, V.I. Odinokov, E.A. Dmitriev, A.I. Evstigneev, O.V. Bashkov, Numerical simulation of stress-strain state of electrophoretic shell molds, ЮР. Conf. Series: Journal of Physics: Conf. Series. 894 (2017) 012125 doi:10ю1088/1742-6596/894/1/012125.

DOI: 10.1088/1742-6596/894/1/012125

[4] G.I. Timofeev, А.I. Evstigneev L.F. Lobanova et.al., Reinforcement of shell molds during investment casting, Foundry production, 7 (1980) 20-21.

[5] V.A. Ozerov, Investment casting, Endorsed by 4-th edition, revised and enlarged edition, Machine building, Moskow, (1994).

[6] I.G. Sapchenko, Structure and properties of porous shell molds being used for investment casting, Dalnauka, Vladivostok, (2003).

[7] I.G. Sapchenko, S.A. Nekrasov, S.G. Zhilin, M.V. Shtern., Stress-strain state of shell molds being used for investment casting.,: Institute of Machines Science and Machine Building of Far Eastern Branch of the Russian Academy of Science, Komsomolsk-na-Amure, (2005).

DOI: 10.17084/2012.i-1(9).15

[8] A.I. Evstigneev, V.I. Odinokov, V.V. Petrov, E.A. Dmitriev, Mathematic modeling of stress-strain state of shell molds being used for investment casting, Dalnauka, Vladivostok, (2009).

[9] V.I. Odinokov, G.M. Sevastianov, I.G. Sapchenko, Evolution of stress state of ceramic mold under nonsteady external heat impact, Mathematic modeling, Т. 22, 11 (2010) 97-108.

[10] G.M. Sevastianov, V.K. Odinokov, I.G. Sapchenko, Optimization of flame retardant ceramic mold structure, Reporter of Samara State Technical University. Series Technical sciences, 4 (27) (2010) 101-108.

[11] G.M. Sevastianov, V.I. Odinokov, I.G. Sapchenko, Crack formation in ceramic molds during metal casting, Strain and destruction of materials, 10 (2010) 25-28.

[12] A.I. Evstigneev, E.A. Dmitriev, V.I. Odinokov, A.V. Sviridov, V.V. Petrov, Process backgrounds for setting the problems on mathematic modeling of stress-strain state of shell molds being used for investment casting, Scholarly Notes of Komsomosk-na-Amure State Technical University, IV-1(32), (2017) 66-77.

DOI: 10.4028/www.scientific.net/msf.857.565

[13] R. Cristensen, Introduction into composite mechanics, Mir, Moscow, (1982).

[14] V.I. Odinokov, A.N. Prokudin, A.M. Sergeeva, G.M. Sevastianov, Certificate of State registration of ODYSSEY software for PC No. 2012661389. ODYSSEY. Registered in Register of programs for PC dtd. December 13, (2012).

[15] V.I. Odinokov, B.G. Kaplunov, A.V. Peskov, A.A. Bakov, Mathematic modeling of complicated processes, Nauka, Moscow, (2008).
