Buckling Problems of Structurally-Anisotropic Composite Panels of Aircraft with Influence of Production Technology

Abstract:

The different approaches were analyzed to investigate the buckling problems of structurally-anisotropic panels made from composite materials. Aircraft composite structure design in the field of production technology is the outlook research trend. New mathematical model relations for the buckling investigation of structurally-anisotropic panels comprising composite materials are presented in this study. The primary scientific novelty of this research is the further development of the theory of thin-walled elastic ribs related to the contact problem for the skin and the rib with an improved rib model. One considers the residual thermal stresses and the preliminary tension of the reinforcing fibers with respect to panel production technology. The mathematical model relations for the pre-critical stressed state investigation of structurally-anisotropic panels made of composite materials are presented. Furthermore, the mathematical model relations for the buckling problem investigation of structurally-anisotropic panels made of composite materials are presented in view of the pre-critical stressed state. The critical force definition of the general bending form of the thin-walled system buckling and the critical force definition of the many-waved torsion buckling are of the most interest in accordance with traditional design practices. In both cases, bending is integral with the plane stress state. Thus, the buckling problem results in the boundary value problem when solving for the eighth order partial derivative equation in the rectangular field. The schematization of the panel as structurally-anisotropic has been proposed as a design model when and the critical forces of total bending form of buckling are determined. For a many-waved torsion buckling study, one should use the generalized functions set. The solution is designed by a double trigonometric series and by unitary trigonometric series. A computer program package is developed using the MATLAB operating environment. The computer program package has been utilized for multi-criteria optimization of the design of structurally-anisotropic aircraft composite panels. The influence of the structure parameters on the level of critical buckling forces for bending and for torsion modes has been analyzed. The results of testing series are presented.

• Periodical: Materials Science Forum (Volume 971)
• Pages: 45-50
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.971.45
• Online since: September 2019
• Authors: Lubov' Mikhailovna Gavva*
• Keywords: A-Symmetric Package Structure, Bending Mode, Buckling, Force Temperature Action, General Boundary Conditions, Lateral Set, MATLAB, Non-Centric Longitudinal, Panels Made of Composite Materials, Pre-Critical Stress State, Technology Temperature Action, Thin-Walled Rib, Torsion Mode

References

[1] C.S. Chen, C.Y. Lin, R.D. Chien, Thermally induced buckling of functionally graded hybrid composite plates, Int. J. Mech. Sci. 53 (2011) (1) 51-8.

DOI: 10.1016/j.ijmecsci.2010.10.006

[2] L. Huang, A.H. Sheih, C.T. Ng, M.C. Griffin, An efficient finite element model for buckling analysis of grid stiffened laminated composite plates, Compos. Struct. 122 (2015) 41-50.

DOI: 10.1016/j.compstruct.2014.11.039

[3] M. Kazemi, A new exact semi-analytical solution for buckling analysis of laminated plates under biaxial compression, Arch. Appl. Mech. 85 (11) (2016) 1667-77.

DOI: 10.1007/s00419-015-1011-x

[4] C. Kim, Y.K. Kim, W. Choi, Trans. Kor. Soc. Mech. Eng. A (8) (2002) 1653-65.

[5] E. Lindgaard, E. Lund, K Rassmussen, Nonlinear buckling optimization of composite structures considering worst shape imperfections, Int. J. Solids and Struct. 47 (22-23) (2010) 3186-202.

DOI: 10.1016/j.ijsolstr.2010.07.020

[6] C. Mittelstedt, K.U. Schroder, Local postbuckling of hat-stringer-stiffened composite laminated plates under transverse compression, Compos. Struct. 92 (12) (2010) 2830-44.

DOI: 10.1016/j.compstruct.2010.04.009

[7] E. Shafei, M.Z. Kabir, Dynamic stability optimization of laminated composite plates under combined boundary loading, Appl. Compos. Mater. 18 (6) (2011) 539-57.

DOI: 10.1007/s10443-011-9222-y

[8] R. Vescovini, L. Dozio, Exact refined buckling solutions for laminated platesnunder uniaxial and biaxial loads, Compos. Struct. 127 (2015) 356-68.

DOI: 10.1016/j.compstruct.2015.03.003

[9] E. Yeter, A. Erklig, M. Bulut, Hybridization effects on the buckling behavior of laminated composite plates, Compos. Struct. 118 (2014) 19-27.

DOI: 10.1016/j.compstruct.2014.07.020

[10] V.V. Firsanov and L.M. Gavva, The investigation of the bending form of buckling for structurally-anisotropic panels made of composite materials in operating MATLAB system, Structural Mechanics of Engineering Constructions and Buildings, 4 (2017) 66-76 (In Russian).

DOI: 10.22363/1815-5235-2017-4-66-76
