Removal Mechanism of Titanium Alloy Material in Ultrasound Vibration Drilling

Abstract:

In drilling the ultra-slim small diameter deep hole of titanium alloy, the problem of chip breaking and chip removal is common. When the drill is working normally, the ultrasonic vibration can be applied for the drill bit to cut the bit in the vibration to form a pulse. The cutting force waveform in drilling, should select the reasonable vibration frequency, amplitude, feed amount, workpiece rotation and other parameters to match, control the size and shape of the chip, get satisfactory chips, and avoid chip clogging. In this study, the ANSYS finite element simulation software was used to simulate the TC4 drilling process, and the difference between ultrasonic vibration drilling and ordinary drilling was analyzed. Drilling experiments were carried out. The experimental results show that compared with conventional drilling, ultrasonic vibration drilling has better surface quality, reduced tool wear and increased material removal rate.

• Periodical: Materials Science Forum (Volume 993)
• Pages: 3-11
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.993.3
• Online since: May 2020
• Authors: Tian Qi Wang*, Zhan Feng Liu, Yuan Ying Qiu, Ya Zhou Feng, Xiao Lan Han
• Keywords: Deep Hole, Removal Mechanism, Titanium Alloy, Ultra-Slim, Ultrasound Vibration Drilling

References

[1] BARANI A, AMINI S, PAKTINAT H, et al. Built-up edge investigation invibration drilling of Al2024-T6[J]. Ultrasonics. 54 (2014) 1300-1310.

DOI: 10.1016/j.ultras.2014.01.003

[2] ISOBE H, UEHARA Y, HARA K. Effect of ultrasonic vibration drilling on cutting stress distribution[J]. Key Engineering Materials. 523-524 (2012) 191-196.

DOI: 10.4028/www.scientific.net/kem.523-524.191

[3] WANG L J, WANG X, ZHAO H F. Effect of the cutting ratio on cutting forces and the drill life in vibration drilling[J]. The International Journal of Advanced Manufacturing Technology. 24 (2004) 865-872.

DOI: 10.1007/s00170-003-1803-y

[4] MAKHDUM F, PHADNIS V A, ROY A, et al. Effect of ultrasonically-assisted drilling on carbon-fibre-reinforced plastics[J]. Journal of Sound & Vibration. 333 (2014) 5939-5952.

DOI: 10.1016/j.jsv.2014.05.042

[5] Feng Yazhou. A Study and Application of Ultrasonic Vibration Drilling in Small Diameter Deep-holes [D]. Xi'an: Xi'an Shiyou University. (2011).

[6] Liu Zhanfeng, Yang Lihe. Design and Research of Ultrasonic Longitudinal Vibration Drilling Device for Deep Holes. [J]. Machine Tool & Hydraulics. 3 (2007) 56-58.

[7] Tianqi Wang, Zhanfeng Liu. Ultrasonic Axial Vibration Drilling System Design [J]. Machinery Design & Manufacture. 5 (2009) 173-175.

[8] Tianqi Wang, Zhanfeng Liu, Chong Zhang. Study on Technology of Drilling Superfine Deep-hole[J]. Advaced Materials Research. 139-141 (2010) 809-812.

DOI: 10.4028/www.scientific.net/amr.139-141.809

[9] Wang shiqing etc. Deep hole processing technology [M]. Xi'an: Northwestern Polytechnical University Press.(2003).

[10] Lu Danni. Study on Ultrasonic Vibration Boring Technology of Difficult-to-machine Materials (TC4) [D]. Xi'an: Xi'an Shiyou University, (2018).

[11] Wang Tianqi, Liu Zhanfeng, Zhang Yanfang, Li Haitao, Zhang Haidong. Design of Ultrasonic Vibration Device of Drilling Small Diameter Deep- hole[J]. Tool Engineering. 46 (2012) 78-80.

[12] HEISEL U, STEHLE T, SCHAAL M, et al. Burr formation in short hole drilling by ultrasonic assistance[J]. Production Engineering.8 (2014) 1-6.

DOI: 10.1007/s11740-013-0493-z

[13] ALAM K, HASSAN E, BAHADUR I. Experimental measurements of temperatures in ultrasonically assisted drilling of cortical bone[J]. Biotechnology & Biotechnological Equipment.29 (2015) 753-757.

DOI: 10.1080/13102818.2015.1034176

[14] T Wang, X Liu, Z Liu, Y Liu, Y Zhang. Analysis used on drilling Inner Blind Hole on Deep Hole [J]. Wireless Personal Communications, 3 (2018) pp.1-12.

DOI: 10.1007/s11277-018-5497-8
