Application Feasibility Study of High Strength Pipeline Steel to Rig Derrick and Substructure

Abstract:

Derrick and substructure is one of rig’s core equipment components, and it is also the most important weight component of rig. The working environment of derrick and substructure is very serious, whose material should has high strength, excellent plasticity, toughness and weldability property. In this paper, the chemical composition, micro-structure, tensile property, impact property, hardness and weldability of high strength pipeline steel with strength grades of X70 (485MPa)~ X100(690MPa) were systematically analyzed. The analysis and study of the service environment of rig derrick and substructure as well as the technical requirements of the material, showed that the performance of high strength pipeline steel was obviously better than that of the same grade high strength low alloy structural steel used in rig derrick and substructure at present, and it can fully meet the technical requirement of rig derrick and substructure. The application of high strength pipeline steel to rig derrick and substructure will improve the service property, optimize the design , and fully ensure the service safety of rig derrick and substructure.

• Periodical: Materials Science Forum (Volume 993)
• Pages: 616-621
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.993.616
• Online since: May 2020
• Authors: Fang Po Li*, Zhi Wei Zhang, Bin Zhang
• Keywords: Derrick, Lightweight, Mechanical Properties, Pipeline Steel, Substructure

References

[1] GB/T 25428-2010 Petroleum and natural gas industries-Drilling and production equipment-drilling and well-servicing structures.

DOI: 10.3403/03175340

[2] GB/T 1591-2018 high strength low alloy structural steels.

[3] API Spec 5L:2018 Line Pipe.

[4] BI Zongyue.welding technology for line pipe. Petroleum industry press.Beijing.(2013).

[5] FENG Yao-rong, GAO Hui-lin, HUO Chun-yong, ea tl. Analysis and Identification of Pipeline Steel Fiber Microstructure, Shaanxi Science and Technology Publishing House, Xi'an, Shaanxi, (2008).

[6] ZHANG Ji-ming, JI lin-kang, HUO Chun-yong, ea tl. Microstructure Identification Atlas of X90/X100 Pipeline Steel. Shaanxi Science and Technology Publishing House, Xi'an, Shaanxi, (2017).
