Dependence of Luminescence Properties of Bonded Si Wafers on Surface Orientation and Twist Angle.

Abstract:

PL spectra of SOI wafers with buried oxide (BOX) layer were measured after dissolution annealing at 1200°. Depending on mutual orientation of starting base and top wafers different patterns of luminescence bands were observed after annealing. While the small fraction of luminescence clearly originated from dislocation related centers, another intensive band appeared in the range 0.8 – 0.95eV with certain dependence of maximum position on the twist misorientation. TEM investigation confirmed the existence of dislocation net at the interface. On the other hand some peculiarities of PL spectra did not support their relation to dislocations. Though a stepped chemical etch of surface layer confirmed the origin of new band being at the interface too. Therefore a nature of possible defects generated due to dissolution of BOX layer is discussed.

You might also be interested in these eBooks

Gettering and Defect Engineering in Semiconductor Technology XIII

View Preview

Info:

Periodical:

Solid State Phenomena (Volumes 156-158)

Pages:

555-560

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.156-158.555

Citation:

Cite this paper

Online since:

October 2009

Authors:

E.A. Steinman, Oleg Kononchuk, A.N. Tereshchenko, A.A. Mazilkin

Keywords:

Dislocation, Luminescence, Silicon, Wafer Bonding

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] V.V. Kveder, E.A. Steinman, S.A. Shevchenko, and H.G. Grimmeiss, Phys. Rev. B 51, 10520 (1995).

Google Scholar

[2] E.A. Steinman, V.I. Vdovin, T.G. Yugova, V.S. Avrutin, and N.F. Izyumskaya Semicond. Sci. Technol. 14, 582 (1999).

DOI: 10.1088/0268-1242/14/6/316

Google Scholar

[3] Hirth, J. P., and Lothe, J., 1982, Theory of Dislocations (New York: McGraw-Hill).

Google Scholar

[4] Steinman, A.N. Tereshchenko, V. Ya. Reznik, R.J. Falster, pss (a), 204, No. 7, 2238-2247 (2007).

Google Scholar

[5] O. Kononchuk, F. Boedt, F. Allibert Solid State Phenomena B, 131-133, 113 (2008).

DOI: 10.4028/www.scientific.net/ssp.131-133.113

Google Scholar

[6] N. Zakharov, E. Pippel, P. Werner, V. Vdovin, M. Milvidskii, M. Ries, M. Seacrist, R. Falster, and U. Gösele, Proceedings of the Microscopy of Semiconducting Materials XVI conference (2009).

DOI: 10.4028/www.scientific.net/ssp.156-158.85

Google Scholar

[7] S. Pizzini, M. Guzzi, E. Grilli, G. Barionetti, J. Phys. Condense Matter, 12, 10131 (2000).

Google Scholar
