Energy-Saving Mechatronic System for Fatigue Tests of Materials under Variable-Amplitude Proportional Bending and Torsion

Abstract:

The paper presents structure and principles of operation of the fatigue test stand for specimens subjected to polyharmonic proportional bending and torsion. The stand is equipped with a digital control system based on data acquisition board Daqboard/2000 and LabVIEW environment. The history of polyharmonic loading is a sum of four harmonic components of various amplitudes, frequencies and phases adjusted by means of four rotating disks with unbalanced masses of the inertial vibrator. Application of a computer with the software elaborated by the authors and the control system enables determination of fatigue characteristics of the material under constant or variable amplitude bending, torsion and any combination of bending with torsion.

• Periodical: Solid State Phenomena (Volume 164)
• Pages: 67-72
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.164.67
• Online since: June 2010
• Authors: Wojciech Macek, Ewald Macha
• Keywords: Control System, Fatigue Test

References

[1] Achtelik H.: A device for fatigue tests under plane, non-synchronously variable stress state, (22. 03. 2004. P 366487) The Bulletin of the Polish Patent Office, No. 20 (200, p.63 (in Polish).

[2] Garud Y. S.: Multiaxial fatigue: a survey of the state of the art, Journal of Testing and Evaluation, Vol. 9, No. 3 (1981), pp.165-178.

[3] E. Macha, W. Będkowski, T. Łagoda (Eds): Multiaxial Fatigue and Fracture, ESIS Publication 25, Elsevier, Amsterdam (1999).

[4] Macha E.: A review of energy- based multiaxial fatigue failure criteria, The Archive of Mechanical Engineering, Vol. XLVIII, No. 1 (2001), pp.71-101.

[5] Macha E. Garbacz G.: Design features, operation principle and parameters of the machine MZGS-100 PL/PZ for fatigue testing of materials with polyharmonic bending with torsion, Przegląd Mechaniczny, No. 11 (2001), pp.29-34 (in Polish).

[6] Bendat J. S., Piersol A. G.: Random Data. Analysis and Measurment Procedures, John Wiley and Sons Inc., New York (1976).

[7] Bitter R.: LabVIEW Advanced Programming Techniques, 2nd Edition.

[8] User's Manual for ATV 28, Schneider Electric (2000)-(2002).

[9] DAQBOARD-2000 Series User's Guide, IOtech Inc. (2004).

[10] DBK16 2-Channel Strain Gage Expansion Card, IOtech Inc. (2005).

[11] DBK Option Cards and Modules, IOtech Inc. (2004).

[12] Inductive sensors, Turck Catalogue (2008).
