Toothed Gear Dynamic Model as a Tool for Assist Diagnosis its Technical Condition

Abstract:

This article presents the results obtained with use of author's dynamic model of gears working on power circulating test stand. It was assumed, that properly defined and next identified model can be used to analyze dynamic phenomena in meshing and bearings of gears.The article includes results of simulations of gear with chipped tooth and with partial crack of the pinion. Results of analysis shown, that the occurrence of meshing deviations, makes the detection of damages in the early stages of their growth difficult and the detection may be not possible without using methods of advanced signal analysis.

• Periodical: Solid State Phenomena (Volume 236)
• Pages: 228-235
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.236.228
• Online since: July 2015
• Authors: Grzegorz Peruń*
• Keywords: Computer Simulation, Dynamic Model, Gear

References

[1] C. Cempel: Basics of vibro-acoustic diagnostics of machines (in Polish). Wydawnictwa Naukowo-Techniczne. Warszawa (1982).

[2] A. Grządziela, M. Kluczyk: An application of order tracking procedure for diagnosis technical state of rotor system in shut-down process. Journal of KONES Powertrain and Transport, Vol. 20, No. 1 (2013).

DOI: 10.5604/12314005.1135323

[3] J. Kozuba, B. Łazarz, R. Konieczko: The impact of the design features of helicopters and their conditions of service of the noise emitted in the interior of the aircraft and its environment (in Polish), Aviation mechanics (ISBN 978-83-932107), ML-XV, 2012, pp.343-359.

[4] P. Krzyworzeka, W. Cioch: Demodulation of non-stationary machine vibration using cycle-time scale, Archives of Acoustics, vol. 31 no. 2, 2006, p.167–177.

[5] B. Łazarz, G. Peruń: Dynamic model of the gears working in circulating power system (in Polish). Scientific Papers, Silesian University of Technology nr 1834 Transport 2006 z. 63.

[6] B. Łazarz, G. Peruń: Identification and verification of simulation model of gears working in circulating power system. Diagnostyka No. 4(52) 2009, pp.55-60.

[7] B. Łazarz, G. Peruń: Influence of construction factors on the vibrational activity of the gearing. Transport Problems 2012 t. 7 z. 2, pp.95-102.

[8] B. Łazarz, G. Peruń: Modeling of damages of rolling bearing elements in gears working in circulating power system (in Polish). Scientific Papers, Silesian University of Technology nr 1803 Transport 2008 z. 64, pp.201-208.

[9] B. Łazarz, G. Peruń: Modeling of surface wear of wheel teeth in gear working in the power transmission system for diagnosis purposes (in Polish). Scientific Papers, Silesian University of Technology nr 1834 Transport 2010 z. 69, pp.91-96.

[10] L. Müller: Toothed gears. Dynamics (in Polish). Warszawa, WNT (1986).

[11] G. Peruń: The influence of constructional, operational and technological factors on the vibroactivity of the power transmission system with toothed gear (in Polish). Doctoral dissertation. Silesian University of Technology, Katowice (2010).

[12] Piľa J.: Vibračné monitorovanie vrtuľníkových reduktorov [Vibration monitoring of helicopter reducers]. Nové trendy v rozvoji letectva. Sekcia 1., Letecké strojárstvo a environmentalistika. – Košice. Vojenská letecká akadémia, 2004, pp.69-74.

[13] Piľa J. & Sloboda A. ml: Diagnostika vznikajúcich porúch lietadlových a iných mechanizmov [Incipient failure diagnostics of aircraft and other mechanisms]. Kvalita a spoľahlivosť technických systémov. Košice TU, (2005).

[14] Piľa J. & Sloboda A. ml.: Vibrodiagnostika planétového prevodu vrtuľníkového reduktora VR-24 [Vibrodiagnostics of helicopter planet gearbox VR-24]. Bezpečnosť, kvalita, spoľahlivosť. Košice TU, (2005).

[15] A. Wilk, H. Madej, B. Łazarz: Vibroactivity of the gear. Influence of design characteristics and wear on the vibroactivity of power transmission system with gear (in Polish). ITE, Katowice-Radom, (2009).
