Minimizing the Dynamic Loads in Pilger Rolling Mill Forholler

Abstract:

For the newly proposed pneumohydraulic drive of workpiece return movement it is researched relations, analysis was carried out and recommendations of selecting values of the initial pressure in the pneumatic chamber, ensuring a rational ratio between the periods of acceleration and deceleration were obtained. A mathematical model and program were created for the calculation of the law of motion of the brake rod with floating piston device using the system variable throttling the flow of the working fluid along the movement in the brake chamber. Based on the developed model the numerical analysis is made to assess the impact of the inner surface of the brake axle box on the final rate of the brake piston, as well as the effect of the location and change in the area of additional throttling apertures therein on the trend values of the maximum braking acceleration of moving masses. An algorithm of determining the constants and variables control law of motion, minimizing the maximum values of dynamic loads per cycle movement of the workpiece is obtained. It is shown that the proposed framework of the rod system of the workpiece return movement in the working cage with a floating piston ensures reduce the moving masses and increases the rigidity of the movable rod. The calculated relations for the definition of effort mobile carriage prop, providing gapless its support with mechanism of feed limit, are obtained.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 1034-1039
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.1034
• Online since: September 2017
• Authors: Yu.B. Chechulin*, Yu.A. Popov
• Keywords: Brake Chamber, Floating Piston, Mechanism of Feed Limit, Pneumatic, Variable Throttling

References

[1] V.N. Danchenko, A.P. Kolikov, B.A. Romantcev, S.V. Samusev, The technology of pipe production, M-Intermet Engineering, (2002).

[2] S.N. Filatov, B.Y. Sokolinsky, Y.B. Chechulin, Y.A. Popov, Forholler of the pilger mill, Russian Federation patent for invention 2547588.

[3] Y.B. Chechulin, Y.A. Popov, I.A. Filimonov, Research of the forholler Pilger Mill work, Steel. 12 (2011) 32-34.

[4] Yu.B. Chechulin, Yu.A. Popov, S.N. Filatov, B.Y. Sokolinsky, The choice of rational parameters of the feeding apparatus Pilger Mill, Steel. 12(2013) 36-39.

[5] Yu.B. Chechulin, Yu.A. Popov, Dynamic analysis of hydraulic pneumatic propulsion on the example of the forholler of the pilger rolling mill, Modern problems of science and education, 1 (2015).

DOI: 10.4028/www.scientific.net/ssp.265.1034

[6] Yu.B. Chechulin, E.U. Raskatov, Yu.A. Popov, Simulation of Process of Hot Pilgrim Rolling, Recent advances in finite differences and applied and computational mathematics, (2013).

[7] Yu.A. Popov, Yu.B. Chechulin, V.M. Ziomkovsky, Choice of rational characteristics of the brake feeder apparatus pilgerstana, Collection of works of the VII International Youth Scientific and Practical Conference «Innovative technologies in metallurgy and machine building», Yekaterinburg, (2014).
