Modernization of Hot-Rolled Tubes Rolling Method

Abstract:

A new method of hot-rolled pipes rolling on the automatic tandem mill is suggested. It consists of two rolling stands. This method allows achieving the rough pipe preovalisation before reaching the automatic mill. The rough pipe preovalisation provides even groove filling and the decrease of pipe wall thickness variation. The rough pipe preovalisation will allow increasing the elongation ratio from 1.5 to 2.0 on the lengthwise rolling stand no. 1 and decreasing the elongation ratio on the piercing mill, therefore the chance of rolling skin formation on the external surface of the pipe is decreased. The way to reduce the probability of the formation of a guide mark defect due to the kinematic tension during rolling on a stub mandrel with rough tube preovalisation is investigated. The influence of the kinematic tension factor on the pipe forming in the groove taper at a lengthwise rolling with rough tube preovalisation is explored.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 1048-1052
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.1048
• Online since: September 2017
• Authors: Dmitry Pavlov*, Aleksandr Bogatov, E.A. Pavlova
• Keywords: Automatic Mill “Tandem”, Coefficient of Rough Pipe Ovalisation, Finite Element Simulation, Kinematic Tension, Pipe Rolling-Off, Stub Mandrel

References

[1] V.V. Kharitonov, A.A. Bogatov, V. Yu. Vakhrushev, Equipment for Pipe Rolling, Extrusion and Drawing: Ekaterinburg, USTU-UPI, (2008).

[2] I.N. Potapov, A.P. Kolikov, V.M. Druyan, Theory of Pipe Making, Metallurgiya, Moscow, (1991).

[3] V.N. Danchenko, A.P. Kolikov, B.A. Romantsev, Pipe-Making Technology, Intermetinzhiniring, Moscow, (2002).

[4] A.P. Karamyshev, I.I. Nekrasov, A.I. Pugin, A Manual for the program Deform-3D Software Package: Ekaterinburg, UrFU Publ., (2010).

[5] A.A. Bogatov, D.A. Pavlov, S.V. Lipnyagov, V.N. Suvorov, Simulating the formation of a guide mark, defect on the inner tube surface in lengthwise rolling, Proizvodstvo prokata, 8 (2012) 37-39.

[6] A.A. Bogatov, D.A. Pavlov, E.A. Dresvyankina, Development of a mathematical model for a new process of lengthwise pipe rolling: In Metal Forming 2014, Fundamental Problems. Advanced Materials and Technologies, Ekaterinburg UrFu Publ., (2014).

DOI: 10.4028/www.scientific.net/amr.1127.127

[7] A.A. Bogatov, E.A. Pavlova, D.A. Pavlov, Finite-element simulation of the process of lengthwise pipe rolling on a stub mandrel: Proceedings of the 3rd International Conference COMAT, (2014).

DOI: 10.4028/www.scientific.net/amr.1127.127

[8] A.A. Bogatov, D.A. Pavlov, S.V. Lipnyagov, V.N. Suvorov, E.A. Pavlova, Rolling hot deformed pipes on a stub mandrel: Steel in Translation, 44(12) (2014) 912-915.

DOI: 10.3103/s0967091214120055
