Research on Metal Forming in Pipe Ends Upsetting Process

Abstract:

Oil country tubular goods (OCTG) are widely used in oil and gas industry. In order to increase joint efficiency of the oil country tubular goods, the process for upsetting their ends is applied. However, the weakness of this upsetting technology is a frequent defect creation on the inner surface of the final product. These imperfections are surface breakings that reduce the effective pipe wall thickness; they are detected close to the upset ends of the pipe. Computer simulation and full-scale experiment were used to study this defect nucleation. According to this research, the occurrence of defects is correlated with average pipe wall thickness, non-uniform wall thickness of the blank, heating mode and friction conditions. The results of full-scale experiment confirm the main conclusions made in the course of the finite element simulation. The research results define the interdependence of actual size of the blank and the operating tool calibration.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 1076-1080
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.1076
• Online since: September 2017
• Authors: Mikhail Erpalov*, Aleksandr Bogatov
• Keywords: Defect, Finite Element Simulation, Full-Scale Experiment, OCTG, Tool Calibration, Upset

References

[1] M.V. Erpalov, Development of OCTG ends upsetting technology at JSC «PNTZ», Proceedings of the International scientific and engineering Congress OMD 2014. Fundamental problems. Innovative Materials and Technologies", Publishing House "Bely veter, Moscow. 2 (2014).

[2] M.V. Erpalov, G.N. Kondratieva, A.A. Bogatov, Upgrading pipe ends upsetting technology in order to increase the efficiency of hydraulic presses SMS Meer, Proceedings of the International Conference Innovative technologies in metallurgy and mechanical engineering, Publishing House Ural Univercity, Ekaterinburg. (2014).

[3] M.V. Erpalov, The research of pipe ends upsetting process on hydraulic presses to enhance their quality, The final report on research carried out at Ural Federal University named after the first President of Russia B.N. Yeltsin, Supervisor A.A. Bogatov, Executor M.V. Erpalov, Ekaterinburg, (2013).

DOI: 10.17580/tsm.2018.04.10

[4] API 5CT. Specification for Casing and Tubing. Ninth edition, Effective Date 2012-01-01, Published by American Petroleum Institute (API), (2011).

[5] GOST R 50278-92. Drill pipes with welded locks. Technical conditions, Effective Date 1994-01-01, Publishing House Standartinform, Moscow, (2010).

[6] V.A. Tkachenko [et al. ], The pipes for the oil industry, Metallurgy, Moscow, (1986).

[7] V. Ja. Ostrenko, Technological features of pipes upsetting in closed tool, Metallurgical and Mining Industry. 1 (1965) 33-35.

[8] V. Ja. Ostrenko, Analytical method for determining the energy-power parameters of the pipe ends upsetting, Proceedings VNTITI Production of pipes, Metallurgy, Moscow. 20 (1968) 223-230.

[9] I. Ja. Tarnowski [et al. ], Theory of metal forming, State Science and Technology Publishing House of ferrous and non-ferrous metallurgy, Moscow. (1963) 382-387.
