Stressed State of the Shaped Casting under the Impact of Hindered Contraction

Abstract:

The analysis of the bending deformation effect and the central tension arising from hindered contraction of the shaped casting, its stress-strained state, leading to the formation of hot cracks in it has been given in the course of the conducted work. The influence of the main casting parameters and the mold has been studied and their relationship with emerging strains in the molded casting has been determined. The impact on the quantity of the emerging strain of bending stress under hindered contraction has been defined and confirmed by practical calculations. It has been shown that the bending stress is much higher than the emerging tensile stress in the considered conditions. It has been found that the length of the element of hindering and the compliance of a moldable mixture exerts a strong influence on the stress-strained state of the shaped casting.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 1092-1098
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.1092
• Online since: September 2017
• Authors: V.M. Kolokol’tsev, A.S. Savinov, A.S. Tuboltseva*
• Keywords: Casting, Hindered Contraction, Length of Hindering Element, Mixture Compliance, Stress, Wall Thickness

References

[1] S.S. Zhukovsky, Strength of the casting mold, Mechanical engineering, Moscow, (1989).

[2] V.A. Smolko, E.G. Antoshkina, Predicting the reliability of molds and cores made of synthetic mixtures with allowance for anharmonicity, Proceedings of the XII International Congress of Foundry Men, Alekseev NSTU, Nizhny Novgorod, (2015).

[3] M. Hojny, Multiscale modelling of mechanical properties of steel deformed in semi-solid state - experimental background, Key Engineering Materials, 643-650.

DOI: 10.4028/www.scientific.net/kem.622-623.643

[4] J. Klepaczko, Crack Dynamics in Metallic Materials, (1990).

[5] D. Hills, P. Kelly, D. Dai, A. Korsunsky, Solution of Crack Problems, (1996).

[6] H. Fredriksson, M. Haddad-Sabzevar, K. Hans-son & J. Kron, Theory of hot crack formation, Materials Science and Technology. 21(5) (2005) 521-530.

DOI: 10.1179/174328405x29276

[7] C. Davidson, , D. Viano, , L. Lu, D. St John, Observation of crack initiation during hot tearing, International Journal of Cast Metals Research. 19(1) (2006) 59-65.

DOI: 10.1179/136404606225023291

[8] A. Ochsner, L.F.M. da Silva, H. Altenbach, M. Hojny, Physical simulation of steel deformation in the semi-solid state, Advanced Structured Materials, 47, 85-119.

DOI: 10.1007/978-3-319-40863-7_7

[9] A. S. Savinov A. S. Tubol'tseva D. V. Varlamova, Calculation of thermal field for damp sand-clay mold-box, Ferrous metals. 6 (2011) 36-38.

[10] G. Brian, Thomas Issues in thermal-mechanical modeling of casting processes, Iron and Steel Institute of Japan International. 35(6) (1995) 737-743.

DOI: 10.2355/isijinternational.35.737

[11] H.J. Choi, Thermal stresses due to a uniform heat flow disturbed by a pair of offset parallel cracks in an infinite plane with orthotropy, European Journal of Mechanics, (2017) 1-13.

DOI: 10.1016/j.euromechsol.2016.11.009

[12] T.I. Trofimova, The course of physics, Higher School, Moscow, (1997).

[13] Madhukar Vable, Mechanics of Materials, Michigan Technological University, Second Edi-tion, (2014).

[14] K. Traidi, V. Favier, P. Lestriez, M. Saby, P. Mangin, Thermo-mechanical steels behaviors at semi-solid state, AIP Conference Proceedings, (2016).

DOI: 10.1063/1.4963418

[15] V.M. Kolokol'tcev, A. S. Savinov, A. S. Tubol'tseva, Calculation of Impeded Shrinkage Casting Processes in Sand Layer, Materials Science Forum, 870 (2016) 516-522.

DOI: 10.4028/www.scientific.net/msf.870.516

[16] V.M. Kolokol'tsev, A.S. Savinov, The simulation of the carbon steel deformation resistance in the brittle-ness temperature range, Proceedings of XV International scientific conference: New technologies and achievements in metallurgy, material engineering and production engineering, Zajemska, Monika (ed), Czestochowa: Czestochowa university of technology, Faculty of production engineering and materials technology, (2014).

DOI: 10.32730/imz.2657-747.19.1.4

[17] A.G.F. Alabi, T.K. Ajiboye, H.D. Olusegun, Measuring the stress, strain and strain-rate in heat treated medium carbon steel samples and finding the constituted material related properties, African Journal of Mathematics and Computer Science Research, 3 (2010).

[18] A. Lanin, I. Fedik, Thermal stress resistance of materials, (2008).

[19] A.S. Savinov, V.M. Kolokol'tsev, K.N. Vdovin, N.A. Feoktistov, Determination of internal forces in the cooled walls of the casting in the implementation of asymmetric elements difficulties, European Conference on Innovations in Technical and Natural Sciences, Proceedings of the 5th International scientific conference, «East West» Association for Advanced Studies and Higher Education GmbH, Vienna, (2014).

[20] A.S. Savinov, Calculation of the stress state in the integration of asymmetric elements of hindering of a molded piece into the layer of a molding sand of variable rigidity, Bulletin of the Nosov Magnitogorsk State Technical University. 3 (2015).
