Theoretical and Experimental Investigation of Vibration Damping Sheet Dynamic Behavior

Abstract:

A great deal of attention is presently being drawn to the question of noise and vibration damping. One of the basic means of the effective damping of unfavorable noises and vibrations is the usage of special sheets with high vibration and noise damping properties in thin-slab structures. In this article the results of a study of the dynamic behavior (of the loss factor) of multilayer vibration damping sheets are being described. The aim of this article is to show the design optimization of multilayer vibration damping sheets, carrying a high loss factor. The theoretical prerequisites for the structure optimization of vibration damping sheets, having a high loss factor, have been determined. The experimental studies on the influence of the thickness of the vibration damping layer, thickness and Young’s modulus of experimental with theoretical data have also been carried out. More effective designs of multilayer vibration damping sheets have been scientifically substantiated.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 439-444
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.439
• Online since: September 2017
• Authors: D.V. Cherkasov*, Yuriy V. Yurkin, V.V. Avdonin
• Keywords: Damping Sheet, Dynamic Behavior, Loss Factor, Vibration Damping Material

References

[1] SNiP 23-03-2003, Building regulations 23-03-2003, Noise protection, GosStroy Rossii, Moscow, (2003).

[2] ASTM E1179-13, Standard Specification for Sound Sources Used for Testing Open Office Components and Systems, ASTM International, West Conshohocken, PA, (2013).

[3] ISO 717-2: 1996, Acoustic-Rating of sound insulation in buildings elements, Part 2: Impact sound insulation.

DOI: 10.3403/30379022

[4] L. Nielsen, Mechanical Properties of Polymers and Composites, Marcel Dekker, Inc, New York, (1974).

[5] D.K. Rao, Vibration of short sandwich beams, J. Sound Vibr., 52 (1977) 253-263.

[5] C. W. de Silva, Vibration damping, control, and design, Taylor & Francis Group, (2007).

[6] D. Thorby, Structural Dynamics and Vibration in Practice, Elsevier Ltd., (2008).

[7] E.M. Kerwin, Damping of flexural waves by a constrained viscoelastic layer, J. Acoust. Soc. Am., 31 (1959) 952-962.

DOI: 10.1121/1.1907821

[8] D.J. Mead, S. Markus. The forced vibration of a three layer damped sandwich bam with arbitrary boundary conditions, J. Sound Vibr., 10 (1969) 163-175.

DOI: 10.1016/0022-460x(69)90193-x

[10] D.J. Mead, Flexural vibration of damped sandwich beams, J. Sound Vibr., 10 (1982) 163-175.

[11] N.N. Miles, P.G. Reinhall, An analytical model for the vibration of laminated beams including the effects of both shear and thickness deformation in the adhesive layer ASME, J. Vibr. Acoust., 108 (1986) 56-64.

DOI: 10.1115/1.3269304

[12] Y. Frostig, M. Baruch, Free vibrations of sandwich beams with a transversely flexible core: a high order approach, J. Sound Vibr., 176 (1994) 195-208.

DOI: 10.1006/jsvi.1994.1368

[13] J. Vaswani, N.T. Asnani, B.C. Nakra, Vibration and damping analysis of curved sandwich beams with a viscoelastic core, J. Composite Struct., 10 (1988) 231-245.

DOI: 10.1016/0263-8223(88)90021-9

[14] S. He, M.D. Rao, Prediction of loss factors of curved sandwich beams, J. Sound Vibr., 159 (1992) 101-113.

DOI: 10.1016/0022-460x(92)90453-5

[15] B. -G. Hu, M. A., Dokainish, Damped vibrations of laminated composite plates – modeling and finite element analysis, J. Finite Element in Analysis and Design., 25 (1993) 103-124.

DOI: 10.1016/0168-874x(93)90059-y

[16] V.D. Cherkasov, Yu.V. Yurkin, E. A Nad'kin, Optimization of constructions of vibration damping sheets on the basis of non-curing sealants, Krovel'nyye i izolyatsionnyye materialy, 1 (2009) 54-56.

[17] V.D. Cherkasov, Yu.V. Yurkin V.V. Avdonin, Bitumen-rubber mixture for effective vibration damping sheets, J. Magazine of Civil Engineering, 8 (2013) 7-13.

DOI: 10.5862/mce.43.2

[18] V.D. Cherkasov, Yu.V. Yurkin, V.V. Avdonin, Vibration damping sheets working in the wide range of temperatures effectively, Regional'naya arkhitektura i stroitel'stvo, 3 (2013) 46-49.

[19] A. Nashif, D. Jones, J. Henderson, Vibration Damping, John Wiley and Sons, (1985).

[20] Nikiforov A. S. Vibration damping on ship, Sudostroyeniye, (1979).
