Influence of Electrode Gap’s Value in Electron Gun on the Penetrating Ability of Electron Beam during the Implementation of Additive Processes

Abstract:

The urgency of experimental study of the formation of powerful electron beams in technological electron guns is substantiated. The design of a technological electron gun of ELA type is described and the possibility of adjusting the electrode gap for changing characteristics of the beam being formed is shown. A series of experiments on the melting of plates (of steel 30 and titanium alloy VT6Сh (Fe up to 0.4%; C up to 0.1%; Si up to 0.07%; V = 3.5-4.5%; N up to 0.05%; Ti = 87.62-90.63%; Al = 5.5-6.75%; O = 0.07-0.2%; H < 0.01%; other elements up to 0.3%) were carried out, during which the electrode gap was varied. Analysis of obtained macrosections of melting regions is made and conclusions about the effect of magnitude of the electrode gap on the shape and transverse dimensions of melting regions are drawn.

• Periodical: Solid State Phenomena (Volume 284)
• Pages: 300-305
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.284.300
• Online since: October 2018
• Authors: M.S. Gribkov*, M.A. Portnov, A.S. Kozhechenko
• Keywords: Additive Processes, Electron Beam Welding, Electron Gun, Electron-Beam Technologies, Penetration Area, Technology of Structural Materials

References

[1] M.A. Zlenko, M.V. Nagaitsev, V.M. Dovbysh, Additive technologies in mechanical engineering, Manual for engineers, Moscow: State Research Center of the Russian Federation, Federal State Unitary Enterprise «NAMI», (2015).

DOI: 10.17580/tsm.2019.01.06

[2] P. Jansky, J. Zlamal, B. Lencova, M. Zobac, I. Vlcek, T. Radlicka, Numerical simulations of the thermionic electron gun for electron-beam welding and micromachining, Vacuum. 84(2) (2009) 357-362.

DOI: 10.1016/j.vacuum.2009.07.007

[3] A.V. Shcherbakov, M.V. Ivashchenko, A.S. Kozhechenko, M.S. Gribkov, Parametric analysis in the design of technological electron beam guns, Russian electrical engineering, 87(1) (2016) 41-45.

DOI: 10.3103/s1068371216010089

[4] A.V. Shcherbakov, R.V. Rodyakina, D.A. Gaponova, V.K. Dragunov, Ionization of gases in welding electron guns, Welding Production. 11 (2017) 24-30.

[5] V.N. Balashov, V.K. Dragunov, A.L. Goncharov, E.V. Terentyev, Modeling of welding electron guns: a tutorial, Moscow: Veche, (2016).

[6] A.V. Shcherbakov, V.V. Novokreshchenov, R.V. Rodyakina, V.N. Lastovirya, Equipment of electron-beam complexes for the production of modern energy products: a manual, Moscow: Veche, (2016).

[7] Ya. Gibson, D. Rosen, B. Staker, Additive Production Technologies. Three-dimensional printing, rapid prototyping and direct digital production, Moscow: Technosphere, (2016).

[8] A.A. Kaydalov, E.I. Istomin, Engineering description and instruction manual for welding electron guns (UL-119, EBA-15, EBA-30, EBA-60/60, EBA-60B), Kiev: Institute of Electric Welding named after E.O. Paton, (2003).

[9] A.A. Kaydalov, Electron-beam welding and related technologies: 2nd ed. Kiev: Ecotechnology, (2004).

[10] V.V. Smalyuk, Diagnostics of beams of charged particles in accelerators. Ed. Corresponding Member of the Russian Academy of Sciences N.S. Dikansky. Novosibirsk: Parallel, (2009).

[11] A.V. Shcherbakov, R.V. Rodyakina, A.S. Kozhechenko, D.A. Gaponova, A.L. Goncharov, V.K. Dragunov, An experimental study of current-density distributions of a technological electron beam // Technical Physics Letters, 43(11) (2017) 958-960.

DOI: 10.1134/s1063785017110104
