Growth of ZnO Microstructure on Porous Silicon

Abstract:

In this study, Zinc Oxide (ZnO) microstructures were grown on porous silicon (PS) using chemical bath deposition (CBD) method by varying the growth time. The field emission scanning electron microscopy (FESEM) revealed the morphology and sized of ZnO. The X-ray diffraction (XRD) spectra indicate the high quality growth of ZnO on PS surface. Raman analyses revealed the peaks shift of E₂(High), characterized wurtzite lattice and indicates good crystallinity of ZnO.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 290)

Pages:

261-266

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.290.261

Citation:

Cite this paper

Online since:

April 2019

Authors:

Nurizati Rosli*, Mohd Mahadi Halim, Md. Roslan Hashim

Keywords:

Chemical Bath Deposition, Electrochemical Etching, Porous Silicon, RF Sputtering, Zinc Oxide
