Remote Plasma Etching of Backend Semiconductor Materials for Reliable Packaging

Abstract:

This paper describes a study on the remote plasma etching of silicon-based semiconductor wafers after laser separation. Several process parameters having impact on the chip reliability, expressed as changes in die material strength, have been studied and optimized. The results show the potential of fluorine-based plasma processing for cleaning dies and improving die performance and thus have a role as a process enabling advanced packaging technologies.
