Development of New Methods for the Production of Large-Diameter Double-Seam Pipes

Abstract:

Modern metallurgical industry consists of many of supporting and main plants, which require constant material investments. The issue of saving material resources, raw materials, etc., as well as reducing the expenditure coefficient of the metal, optimization and flexibility of production, is an important part for metallurgical companies in the conditions of economic instability in the industrial sector. This article describes the newly developed methods for the production of expandable electric welded pipes from two sheets (double-seam). An assessment of the feasibility of implementing the developed methods was made for the production of large diameter double-seam pipes, using modern engineering analysis methods, based on the finite element method (FEM). Technological modes of shaping were selected to produce products that meet customer requirements. The article describes the results of the experimental work, assesses the convergence of the results obtained using CAE-systems and the experimental work in the plant. The developed mathematical models for the production of pipe billets in the main shaping operations have high convergence and can be used in the calculation of new sizes. The use of the developed mathematical models in the specialized software package MSC Software allows evaluating new technological modes and various production methods without risks and financial losses. The proposed new methods for the production of large-diameter double-seam pipes (forming a sheet from two halves and forming a half cylinder) increased productivity and flexibility of production, and also had a positive economic efficiency, due to lower costs for sheet billet. New production methods have proved their working ability and have proved the possibility of practical application (production of an experimental batch).

• Periodical: Solid State Phenomena (Volume 316)
• Pages: 538-548
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.316.538
• Online since: April 2021
• Authors: German S. Batalov*, Alexander A. Lunev, L.V. Radionova, Viacheslav D. Lezin
• Keywords: Development of New Methods for the Production of Double-Seam Pipes, Finite-Element Method, JCOE Method, Process Simulation, Seamed Pipes, Stepped Molding

References

[1] V.Ya. Osadchy, A.S. Vavilin, V.G. Zimovets, A.P. Kolikov, Technology and Equipment for Pipe Production: A Textbook for Universities, Intermet Engineering, Moscow, (2001).

[2] D.M. Kovalenko, V.V. Chander, A method of manufacturing double-seam pipes of large diameter, Russian patent No. 0002667194 (2018).

[3] Yu.M. Matveev, E.M. Halamez, V.Ya. Ivantsov, L.I. Zayonchik, Study of the process of moulding semi-cylinders for the production of large-diameter pipes, Production of welded and seamless pipes 13 (1971) 93-96.

[4] S.V. Samusev, A.V. Luskin, V.V. Boldt, Method for assembling a billet shape after a step moulding in the electric pipe-welded rig 1420 line, University News Ferrous metallurgy 3 (2010) 9-13.

[5] S.V. Samusev, A.V. Luskin, V.V. Boldt, Analysis of the methods of moulding a billet for the production of large-diameter pipes, Steel 12 (2009) 46-49.

[6] S.V. Samusev, A.I. Romantsov, K.L. Zhigunov, V.V. Boldt, M.S. Sigida, Development of technological regimes of the pipe billet forming section in the electric pipe-welded rig 1420 line of Chelyabinsk Pipe Rolling Plant OJSC, Rolling Production 10 (2011) 20-28.

DOI: 10.3103/s0967091212010159

[7] V.A. Shterenzon, Process Modeling: compendium of lectures, Ekaterinburg, (2010).

[8] L. Segerlind, Application of the finite element method: translation from English, Moscow, (1979).

[9] V.I. Kireev, A.V. Panteleev, Numerical methods in examples and problems: a training manual, Moscow, (2004).

[10] L. G. Stepansky, Calculations of metal forming processes, Moscow, (1979).

[11] V.V. Galkin, A.S. Cheburkov, G.V. Pachurin, Assessment of the stress - strain state of metal tubular billets made by step moulding by mathematical modeling, Modern problems of science and education, 2 (2013) 1-9.

[12] A.P. Colic, DY Zvonarev, V.Ya. Besieger, Mathematical model of moulding a sheet billet in the production of welded large-diameter pipes, Plastic deformation of metals: a collection of scientific papers in 2 volumes, Dnepropetrovsk, (2014).

[13] Information on http://ausferr.ru (06.05.2019).

[14] D.M. Makeev, Modernization of the expander in the pipe straight-line of workshop No. 6 of PJSC ChelPipe in order to improve product quality, Thesis of the master of technical sciences, Chelyabinsk, (2018).

[15] V.V. Pravosudovich, V.P. Sokurenko, V.N. Danchenko, Defects of Steel Ingot and Rolled: Reference Edition, Interment Engineering, Moscow, (2006).

[16] F.S. Dubinsky, M.A. Sosedkova, Mathematical design of an experiment in rolling: compendium of lectures, SUSU Publishing House, Chelyabinsk, (2007).

[17] P.A. Volkova, A.B. Shipunov, Statistical data processing in educational research, Ecopress, Moscow, (2008).

[18] G. Palumbo, L. Tricarico, Effect of forming and calibration operations on the final shape of large diameter welded pipes, Journal of Materials Processing Technology 164-165 (2005) 1089 – 1098.

DOI: 10.1016/j.jmatprotec.2005.02.150

[19] V. I. Anuryev, Handbook of the designer - mechanical engineer, Moscow, (2001).

[20] V. Deriks, B. Genser, New technologies for economical and flexible production of large-diameter pipes, Proceedings of the XIII International scientific-practical conf. Pipes 2005", OJSC "RosNITI,, Chelyabinsk (2005) 105-108.
