Designing Barium Titanate Ceramics with High Energy Storage and Mechanical Properties

Abstract:

Designing the fine-grained ceramics with high recoverable energy storage density and excellent mechanical performance, still presents great challenges. Because the ceramics with large pore size and low relative density were obtained by the traditional sintering method, they always exhibit small breakdown strength and poor mechanical properties, which limits the miniaturization and operation of devices in harsh environments. In this paper, we designed the barium titanate ceramics (BT) ceramics with grain size of 252 nm and relative density of 0.92 can be obtained via co-sintering of two sizes of BT particles at 1000 °C for 10 h. The cubic phase BT particles with 80 nm are doped in the tetragonal phase BT particles with 200 nm to obtain tetragonal phase fine-grained BT ceramics. When doped with 80 nm BT particles, the sintering of 200 nm BT particles is promoted. The enhanced sinterability is due to the phase transformation and metastability, which act as sintering aids. The obtained BT ceramics with nanodomains, high energy storage and mechanical properties. The discharge energy density is of 0.81 J/cm³, and the Vickers hardness is 1.75 GPa.

• Periodical: Solid State Phenomena (Volume 335)
• Pages: 67-72
• DOI: https://doi.org/10.4028/p-d89007
• Online since: July 2022
• Authors: Quan Jin*, En Peng Song, Ke Cai, Fen Hua Chen, Zhao Liu
• Keywords: Barium Titanate, Energy Storage, Fine-Grained Ceramics, Mechanical Properties

References

[1] J L Li, F Li, Z Xu, S J Zhang. Multilayer lead-free ceramic capacitors with ultrahigh energy density and effciency [J]. Advanced Materials, 2018, 30(32): 1802155.

DOI: 10.1002/adma.201802155

[2] Z Yang, H L Du, S B Qu, Y D Hou, et al. Significantly enhanced recoverable energy storage density in potassium-sodium niobate-based lead free ceramics [J]. Journal of Materials Chemistry A, 2016, 4(36): 13778-13785.

DOI: 10.1039/c6ta04107h

[3] W B Li, D Zhou, L X Pang, R Xu, et al. Novel Barium titanate based capacitors with high energy density and fast discharge performance [J]. Journal of Materials Chemistry A, 2017, 5(37): 19607-19612.

DOI: 10.1039/c7ta05392d

[4] Y H Huang, Y J Wu, B Liu, T N Yang, et al. From core-shell Ba0.4Sr0.6TiO3@SiO2 particles to dense ceramics with high energy storage performance by spark plasma sintering [J]. Journal of Materials Chemistry A, 2018, 6(10): 4477-4484.

DOI: 10.1039/c7ta10821d

[5] C Q Zhu, X H Wang, Q C Zhao, Z M Cai, et al. Effects of grain size and temperature on the energy storage and dielectric tunability of non-reducible BaTiO3-based ceramics [J]. Journal of the European Ceramic Society, 2019, 39(4): 1142-1148.

DOI: 10.1016/j.jeurceramsoc.2018.11.034

[6] Z M Cai, X H Wang, W Hong, B C Luo, et al. Grain-size-dependent dielectric properties in nanograin ferroelectrics [J]. Journal of the American Ceramic Society, 2018, 101(12): 5487-5496.

DOI: 10.1111/jace.15803

[7] B B Liu, X H Wang, R X Zhang, L T Li. Grain size effect and microstructure influence on the energy storage properties of fine-grained BaTiO3-based ceramics [J]. Journal of the American Ceramic Society, 2017, 100(8): 3599-3607.

DOI: 10.1111/jace.14802

[8] C Zhang, Y Chen, M X Zhou, X Li, et al. Achieving ultrahigh dielectric breakdown strength in MgO-based ceramics by composite structure design [J]. Journal of Materials Chemistry C, 2019, 7(26): 8120-8130.

DOI: 10.1039/c9tc02197c

[9] Z T Yang, H L Du, S B Qu, Y D Hou, et al. Significantly enhanced recoverable energy storage density in potassium–sodium niobate-based lead free ceramics [J]. Journal of Materials Chemistry A, 2016, 4(36): 13778-13785.

DOI: 10.1039/c6ta04107h

[10] P Gao, Z H Liu, N Zhang, H Wu, et al. New antiferroelectric perovskite system with ultrahigh energystorage performance at low electric field [J]. Chemistry of Materials, 2019, 31(3): 979-990.

DOI: 10.1021/acs.chemmater.8b04470

[11] Z N Yan, D Zhang, X F Zhou, H Qi, et al. Silver niobate based lead-free ceramics with high energy storage density [J]. Journal of Materials Chemistry A, 2019, 7(17): 10702-10711.

DOI: 10.1039/c9ta00995g

[12] Q Li, M Y Li, C Wang, M C Zhang, et al. Enhanced temperature stable dielectric properties and energy-storage density of BaSnO3-modifed (Bi0.5Na0.5)0.94Ba0.06TiO3 lead-free ceramics [J]. Ceramics International, 2019, 45(16): 19822-19828.

DOI: 10.1016/j.ceramint.2019.06.237

[13] Q B Yuan, G. Li, F. Z. Yao, S. D. Cheng, et al. Simultaneously achieved temperature-insensitive high energy density and efficiency in domain engineered BaTiO3-Bi(Mg0.5Zr0.5)O3 lead-free relaxor ferroelectrics [J]. Nano Energy, 2018, 52: 203-210.

DOI: 10.1016/j.nanoen.2018.07.055

[14] M X Zhou, R H Liang, Z Y Zhou, X L Dong, Superior energy storage properties and excellent stability of novel NaNbO3-based lead-free ceramics with A-site vacancy obtained via a Bi2O3 substitution strategy [J]. J. Mater. Chem., A 2018, 6: 17896-17904.

DOI: 10.1039/c8ta07303a

[15] Z H Yao, Z Song, H Hao, Z Y Yu, , et al. Homogeneous/inhomogeneous-structured dielectrics and their energy-storage performances [J]. Adv. Mater., 2017, 29: 1601727-1601741.

DOI: 10.1002/adma.201601727

[16] Q. Jin, B. Cui, X. T. Zhang, J. Wang. A binary particle self-assembly sintering method to realize controllable synthesis of fine-grained barium titanate ceramics. J. Electron. Mater. 2021, 50(1):325-335.

DOI: 10.1007/s11664-020-08559-z

[17] Z T Yang, F Gao, H L Du, L Jin, , et al. Grain size engineered lead-free ceramics with both large energy storage density and ultrahigh mechanical properties [J]. Nano Energy, 2019, 58: 768-777.

DOI: 10.1016/j.nanoen.2019.02.003
