Characterization of Barium Hexaferrite (BaFe₁₂O₁₉) from NitrateCompound with Sol-Gel Method for Barium Hexaferrite MagneticMaterials

Abstract:

Barium Hexaferrite is a permanent magnet material known for its excellent quality and relatively inexpensive manufacture. Barium hexaferrite has good stability and can be applied in various technologies. In this research, the synthesis of barium hexaferrite has been successfully made from the primary materials Fe (NO₃)₃ and Ba (NO₃)₂ using the sol-gel method, as well as other materials such as NaOH, chitosan, molasses, acetic acid and distilled water as the primary solvents for several materials. In addition, variations in aging time 0 hours, 2 hours, 4 hours and 6 hours were added to see the effect on morphology, crystal structure and the magnetic properties of barium hexaferrite magnets. The characterization process is carried out with three testing processes, namely X-Ray Diffraction testing (XRD), Scanning Electron Microscopy (SEM) and Vibrating Sample Magnetometer (VSM). From the XRD, it was found that the desired phase of Barium Hexaferrite (BaFe₁₂O₁₉) was formed, while in the SEM testing process, it was seen that the aging time of the barium hexaferrite sample decreased the particle size of the barium hexaferrite BaFe₁₂O₁₉ from an aging time of 0 hours seen 681.459 nm and at an aging time of 6 hours. Visible 538.859 nm particle size formed. The VSM characterization results showed that different aging times did not affect the barium hexaferrite nanomagnets' magnetic properties.

• Periodical: Solid State Phenomena (Volume 345)
• Pages: 77-84
• DOI: https://doi.org/10.4028/p-n1ip8Z
• Online since: July 2023
• Authors: Apang Djafar Shieddieque*, Shinta Virdhian, Moch Iqbal Zaelana Muttahar
• Keywords: Barium Hexaferrite, Molasses, Permanent Magnet, Sol-Gel Method

References

[1] P. Sardjono et al., "Inovasi Teknologi Pembuatan Magnet Permanen Untuk Membangun Industri Magnet Nasional," Pros. InSINas, p.102–108, 2012.

[2] G. Tan and X. Chen, "Structure and multiferroic properties of barium hexaferrite ceramics," J. Magn. Magn. Mater., vol. 327, p.87–90, 2013.

DOI: 10.1016/j.jmmm.2012.09.047

[3] A. D. Shieddieque, S. Virdhian, M. I. Z. Muttahar, and M. R. Muttaqin, "Effects of Sintering Variables on the Physical and Mechanical Properties of Metal Injection Molding Molded 17-4 PH Stainless Steel," 2021. [Online]. Available: www.scientific.net.

DOI: 10.4028/www.scientific.net/msf.1028.403

[4] M. Ginting et al., "Effect of Co and Ni additions as doping materials on the micro-structures and the magnetic properties of barium hexa-ferrites," Case Stud. Therm. Eng., vol. 18, p.100589, 2020.

DOI: 10.1016/j.csite.2020.100589

[5] S. Purnama, P. Purwanto, and W. . Ari, "Synthesis Of Magnetic Barium Hexaferrite Material (BaFe12O9)," J. Kim. Kemasan, vol. 37, no. 2, p.95–102, 2019, [Online]. Available: https://media.neliti.com/media/publications/218319-pengembangan-bahan-magnetik-barium-heksa.pdf.

DOI: 10.24817/jkk.v37i2.1818

[6] V. S. Vladimir, Z. Cvejić, M. Milanović, G. Stojanović, and G. Rakić, "Metal oxide structure, crystal chemistry, and magnetic properties," Magn. Ferroelectr. Multiferroic Met. Oxides, p.313–332, 2018.

DOI: 10.1016/B978-0-12-811180-2.00016-5

[7] F. Mohseni, R. C. Pullar, J. M. Vieira, and J. S. Amaral, "Enhancement of maximum energy product in exchange-coupled BaFe12O19/Fe3O4 core-shell-like nanocomposites," J. Alloys Compd., vol. 806, p.120–126, 2019.

DOI: 10.1016/j.jallcom.2019.07.162

[8] S. Virdhian, R. A. Wulandari, A. F. Mu'arif, A. Setiawan, and B. Sunendar, "PENGARUH TEMPERATUR DAN WAKTU AGING PADA SINTESIS MAGNET," vol. 38, no. 1, p.1–7, 2016.

DOI: 10.32423/jmi.2016.v38.1-7

[9] S. Virdhian, D. H. Prayitno, S. Jamilah, B. Besar, and K. Perindustrian, "NdFeB ALLOYS MAKING FOR PERMANENT MAGNET RAW MATERIALS APPLICATIONS," vol. 38, no. 2, 2016.

[10] A. F. Mu'arif, "PENGARUH WAKTU AGING DAN PEMANASAN LARUTAN TAPIOKA TERHADAP SIFAT MAGNETIK PADA SINTESIS MAGNET NANO BARIUM HEKSAFERIT (BaFe 12 O 19 ) Universitas Pendidikan Indonesia | repository.upi.edu | perpustakaan.upi.edu," p.20–38, 2014.

DOI: 10.32423/jmi.2016.v38.1-7

[11] E. S. Alhwaitat et al., "Effects of synthesis route on the structural and magnetic properties of Ba3Zn2Fe24O41(Zn2Z) nanocrystalline hexaferrites," Ceram. Int., vol. 44, no. 1, p.779–787, 2018.

DOI: 10.1016/j.ceramint.2017.09.247

[12] L. Junliang, Z. Yanwei, G. Cuijing, Z. Wei, and Y. Xiaowei, "One-step synthesis of barium hexaferrite nano-powders via microwave-assisted sol-gel auto-combustion," J. Eur. Ceram. Soc., vol. 30, no. 4, p.993–997, 2010.

DOI: 10.1016/j.jeurceramsoc.2009.10.019

[13] M. Radwan, M. M. Rashad, and M. M. Hessien, "Synthesis and characterization of barium hexaferrite nanoparticles," J. Mater. Process. Technol., vol. 181, no. 1-3 SPEC. ISS., p.106–109, 2007.

DOI: 10.1016/j.jmatprotec.2006.03.015

[14] Y. Maswadeh, "Structural Analysis of Hexaferite Materials," no. August 2014, 2017.

[15] Y. Yunasfi, "ANALISIS STRUKTUR KRISTAL DAN SIFAT MAGNET BAHAN ABSORBER Ni(0,5-x)NdxFe2,5O4 HASIL SINTESIS DENGAN METODE KOPRESIPITASI," Maj. Ilm. Pengkaj. Ind., vol. 12, no. 1, p.25–32, 2018.

DOI: 10.29122/mipi.v12i1.1805
