Alkali Wet Chemicals for Ru with Advanced Semiconductor Technology Nodes

Abstract:

Wet chemicals for ruthenium (Ru) etching are required for the formation of reliable Ru interconnects in advanced semiconductor technology nodes. In the present study, a novel alkali wet etchant, referred to as TK-1, has been developed in order to overcome issues with conventional Ru etchants, such as a low etch rate and the formation of toxic RuO₄ gas. Regardless of the Ru deposition process, TK-1 exhibits a high Ru etching selectivity of greater than 100 relative to dielectric and liner materials. It also suppresses the production of RuO₄ during the etching process. TK-1 has potential applications for Ru recess etching during fully self-aligned via fabrication.

• Periodical: Solid State Phenomena (Volume 346)
• Pages: 325-330
• DOI: https://doi.org/10.4028/p-08cHSp
• Online since: August 2023
• Authors: Yuki Kikkawa*, Yuzan Suzuki, Kohei Saito, Hiroto Yarimizu, Satoko Kanamori, Tomoaki Sato, Toru Nagashima
• Keywords: Backside Cleaning, Bevel Cleaning, Recess Process, RuO₄ Gas, Ruthenium, Surface Roughness, Wet Etching

References

[1] L. G. Wen et al., ACS appl. Mater. Interfaces, 8 (39) (2016), pp.26119-26125.

[2] H. Aoki et al., Extended Abstracts (International Conference on SSDM, Tokyo, 2001), pp.20-21.

[3] I. Povar et al., J. Electrochem. Sci. Eng., 6 (1) (2016), pp.145-153.

[4] T. Saeki et al., Extended Abstracts (The 48th Spring Meeting 2001), The Japan Society of Applied Phys. and Related Soc. (2001), p.830.

[5] R. Segaud et al., ECS Transactions, 25 (5) (2009), pp.329-336.

[6] M. Kunz et al., Makromol. Chem. Macromol. Symp., 20/21 (1988), pp.147-158.
