Stability of Tubular Preforms from Multi-Layer Winding of Composite Tapes Prior to Thermoforming

Abstract:

Some composite preforms lose dimensional stability after mandrel removal during tube winding, leading to pronounced longitudinal expansion and radial contraction for specific layup configurations. This work presents an experimental method for tracking the reorganization of individual wound tapes during mandrel release and uses these measurements to validate a finite element (FE) model designed to capture the underlying deformation mechanisms. The experiments reveal a nonlinear dependence of ribbon elongation on the initial winding angle. Complementary FE parametric studies investigate the effects of tape geometry and mechanical properties, demonstrating that increased mechanical anisotropy amplifies the elongation response. The study also introduces a layer-equivalent stiffness formulation and concludes with FE simulations of multi-tape preforms. Together, these results support the development of improved winding strategies aimed at reducing defects, lowering production costs, and enhancing the structural performance of tubular composite components.

• Periodical: Solid State Phenomena (Volume 387)
• Pages: 21-31
• DOI: https://doi.org/10.4028/p-91sVZi
• Online since: April 2026
• Authors: Nagui Elgaby*, Guillaume Helbert, Nahiene Hamila, Rubén Campos, Audrey Sanchez, Bertrand Laine
• Keywords: Stability, Tape Winding, Tubular Composites
