Design and Construction of a High Speed Inter-Row Cultivator

Abstract:

In many parts of the world, row crops are treated with herbicides. Because of environmental concerns, crop cultivation is suggested as an excellent method of weed control. The object of this study was to design and construct a high speed inter-row cultivator. The speed of plowing has a significant effect not only on the depth of plowing but on factors which affect the quality of soil preparation such as loosening of the upper soil layer, cutting roots of the previous crops, covering and plowing in of weeds, leveling the finished surface of the field, displacement of the son layer and so on. In this study, the designed and constructed cultivator has a toolbar, unit frame, disk coulter and a flat sweep. The unit frame is attached to a tractor mounted tool bar by a suspension linkage. The suspension linkage allows the unit frame to move up and down relative to a tool bar that the cultivator unit is attached to. The numerical analysis was performed with COSMOS/M 1.71 FEM software (Structural Research and Analysis Corporation, CA).

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 4914-4918
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.4914
• Online since: October 2011
• Authors: Yousef Abbaspour-Gilandeh, Zargham Fazel-Niari, Gholamhosein Shahgoli, Malek Bavafa
• Keywords: Construction, Cultivator, Design, Finite Element Method (FEM), High-Speed

References

[1] A. Mouazen and M. Neményi, Finite Element Analysis of Subsoiler Cutting in Non-homogeneous Sandy Loam Soil, Soil and Tillage Research, vol. 51, July 1999, pp.1-15, doi: 10. 1016/S0167-1987(99)00015-X.

DOI: 10.1016/s0167-1987(99)00015-x

[2] A. K. Srivastava, C. E. Goering, R. P. Rohrbach, and D. R. Buckmaster, Soil tillage. Chapter 8 in Engineering Principles of Agricultural Machines, 2nd ed., St. Joseph, Michigan: ASABE. Copyright American Society of Agricultural and Biological Engineers, 2006, pp.169-230.

DOI: 10.13031/2013.41470

[3] COSMOS/M 1. 71., 1994. The Advance Modules, 2nd ed. Structure Research and Analysis Corperation, 2951 28th street, Suite 1000, Santa Monica, CA 90405.

[4] H. M. Hanna, R. G. Hartzler and D. C. Erbach, High-speed Cultivation and Banding for Weed Management in No-Tillage Corn, Applied Engineering in Agriculture, vol. 16, 2000, pp.359-365.

DOI: 10.13031/2013.5220

[5] K. R. Paarlberg, H. M. Hanna, D. C. Erbach and R. G. Hartzler, Cultivator Design for Interrow Weed Control in No-till Corn, Applied Engineering in Agriculture, vol. 14, 1998, pp.353-361.

DOI: 10.13031/2013.19394

[6] Sh. Davoudi, R. Alimardani, A. Keyhani and R. Atarnejad, A Two Dimensional Finite Element Analysis of a Plane Tillage Tool in Soil Using a Non-linear Elasto-Plastic Model, American-Eurasian J. Agric. & Environ. Sci., vol. 3, 2008, pp.498-505.

[7] N. I. Klenin, I. F. Popov and V.A. Sakun, Agricultural Machines, 1st Ed. American Publishing Co. Pvt. Ltd., New Delhi, 1985, pp: 400-418.

[8] P. Sullivan, Principles of Sustainable Weed Management for Croplands, ATTRA Publication #IP039, 2003, available at: http: /attra. ncat. org/attraa-pub/PDF/weed. pdf.
