Experimental and Numerical Analysis for Two Kinds of Impact Vibration of Gear

Abstract:

In this paper, there are two kinds of impact vibration models: rigid impact model and elastic model. The dynamic responses of the two kinds of gear impact models are compared by experimental and numerical analysis. Firstly, establish the motion equations of the two models. Secondly, verify the correctness of the mechanical models through experimental analysis. Comparing the results of the numerical and experimental analysis, we can find that the intensity noise of gear vibration is reduced by the elastic boundary. Finally, the dynamic bifurcation characteristic of dimensionless excitations magnitude and backlash will be analyzed as well.

• Periodical: Applied Mechanics and Materials (Volume 141)
• Pages: 43-48
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.141.43
• Online since: November 2011
• Authors: Lin Yu Su, Yi Qiang Sun, Jian Ming Wen
• Keywords: Bifurcation, Experiment, Gear Transmission, Impact, Spectrum

References

[1] Wen Jianming: Stochastic Model and Chaotic Characteristic of Rattling Vibration [D], (1998).

[2] Sun Yiqiang: Modeling and Experiment of Rattling Vibration with Random Damping [D], (2009).

[3] Pfeiffer F. and Prestl W.: Nonlinear Dynamics Vol. 5 (1994), pp.477-492.

[4] Pfeiffer F. and Kunert A.: Non-linear Dynamics, Vol. 1(1990), pp.63-74.

[5] Feng Qi: Journal of Sound and Vibration Vol. 215(1998) No. 3.

[6] Weng Jianming, Feng Qi: Noise And Vibration Control (1998)No. 5.

[7] Weng Jianming, Feng Qi: Journal of Vibration Engineering Vol. 13 (2000)No. 3.

[8] Pfeiffer F. and Karagiannis K: Non-linear Dynamics (1991)No. 2, pp.367-387.

[9] SUN Yiqiang, WEN Jianming and FENG Qi: Chinses Quarterly Of Mechanics Vol. 31(2010) No. 2, pp.243-249.

[10] WEN Jianming, SUN Yiqiang and FENG Qi: Journal Of Tongji University (Natual Science)Vol. 38 (2010)No. 12, pp.1802-1806.

[11] Jin Dongping, Hu Haiyan: Advances In Mechanics Vol. 29 (1999)No. 2, pp.155-164.
