Seismic Analysis for the Suspended Converter Valve Tower of the UHV

Abstract:

Based on the ANSYS software, a finite element model of a single converter valve tower of the UHV (Ultra High Volt) is built, the structure dynamic characteristics of the converter valve tower is analyzed by the modal analysis method, the earthquake response of the converter valve tower is calculated by the response spectrum analysis method. The prestress effect and the large deformation effect are taken into account in the calculation process, and the seismic responses under some complex loads which combine the earthquake loads and the gravity load are calculated. The results show that lots of natural frequencies of the converter valve tower, which is designed as a flexible structure, very low. The fundamental vibration modes are pendulum sways in X- and Y-direction. The displacements of the horizontal sway response of the converter valve tower are larger than other direction displacements. This conclusion must be considered in the reasonable arrangement design of the valve hall.

You might also be interested in these eBooks

Mechanical, Industrial and Manufacturing Technologies

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 187)

Pages:

196-201

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.187.196

Citation:

Cite this paper

Online since:

June 2012

Authors:

Q.G. Sun, X.F. Wu, J.J. Di, Y.C. Zhou

Keywords:

Earthquake Response, Finite Element Model (FEM), Mode, Response Spectrum Method, UHV

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y. J. Ma, Structural Selection and Anti-quake Analysis of Converter Station Valve Hall, , Electric Power Construction, 2009, vol. 30, pp.37-40.

Google Scholar

[2] Z. H. Liu, H. H. Zhu, and S. Ye, Research of Seismic Response of Suspending Valves in Converter Station, Southern Power System Technology, vol. 3, 2009, pp.24-26.

Google Scholar

[3] L. J. Huang, The Vibration Test and Nonlinear Dynamical Analysis Study of the Valve Hall Structure, WuhanUniversity of Technology, (2007).

Google Scholar

[4] GB/J50011-2001: Code for Seismic Design of Buildings, (2001).

Google Scholar

[5] C. G. Zhang, Application of Ansys to Analysis of Vibration Type Decomposition Response Spectrum of a Concrete Gravity Dam, Yunnan Water Power, vol. 25, 2009, pp.24-27.

Google Scholar

[6] DL/T5223-2005: Technical Rule for Designing HVDC Converter Station, (2005).

Google Scholar
