Composite Anisotropic Conductive Film

Abstract:

Anisotropic conductive film (ACF), is a lead-free and fine-pitch interconnect materials that is commonly used in liquid crystal display (LCD) manufacturing to make and maintain the electrical and mechanical connections from the driver IC to the substrate. A key issue in the ACF technology is the packaging yield or failure probability, and performance of ACF’s material formula composition. This paper utilizes the V-shaped curve method to analyze the failure probability of composite ACF packages with a smart composition or a functional formula. In the proposed model, the probability of opening failures is modeled using a Poisson function, modified to take into account the average conception on the effective conductive area between opposing pads. Meanwhile, the probability estimation of bridging failures is based on the Box-Strip-Brick model between the neighboring pad pairs in the array. The results show the derived probability formulation can involve the probability conceptions of the composite ACF into a complete evaluation computation.

• Periodical: Applied Mechanics and Materials (Volume 302)
• Pages: 182-188
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.302.182
• Online since: February 2013
• Authors: Chao Ming Lin
• Keywords: Anisotropic Conductive Film, Composite, Failure, Probability, V-Shaped Curve Method

References

[1] J. Lau, Low Cost Flip Chip Technologies. McGraw-Hill, New York, (1996).

[2] Johan Liu, Conductive Adhesives for Electrics Packaging, Electrochemical Publications Ltd, (1999).

[3] C. M. Lin, M. H. Su, and W. J. Chang, The Prediction of Failure Probability in Anisotropic Conductive Adhesive (ACA), IEEE Transactions on Device and Materials Reliability. 5 (2005) 255-261.

DOI: 10.1109/tdmr.2005.846979

[4] C. M. Lin, W. J. Chang, T. H. Fang, Analysis of New Anisotropic Conductive Film (ACF), IEEE Transactions on Device and Materials Reliability, 5 (2005) 694-700.

DOI: 10.1109/tdmr.2005.860557

[5] C. M. Lin, Y. L. Chen, H. M. Chu, Modeling of Real-Time Reliability Predicting System on Anisotropic Conductive Film (ACF) Processing, Materials Science and Engineering: A, 432 (2006) 239-244.

DOI: 10.1016/j.msea.2006.06.037

[6] C. M. Lin, Effects of Systematic and Stochastic Errors on Estimated Failure Probability of Anisotropic Conductive Film, IEEE Transactions on Device and Materials Reliability, 7 (2007) 387-398.

DOI: 10.1109/tdmr.2007.907285

[7] C. M. Lin, W. J. Chang, and T. H. Fang, Reliability Analysis of the Fine Pitch Connection using Anisotropic Conductive Film (ACF), Microelectronics Journal, 37 (2006) 565-568.

DOI: 10.1016/j.mejo.2005.10.002

[8] C. M. Lin, C. M. Tan, Y. C. Liu, C. Y. Chu, An Enhanced Bridging Model for Evaluating the Failure Probability of Anisotropic Conductive Film Packages, Optoelectronics and Advanced Materials–Rapid Communications, 3 (2009) 493-500.

[9] C. M. Lin, T. C. Lin, L. M. Chu, Failure on Multilayered Anisotropic Conductive Films (ACF) Packaging, Advanced Materials Research, 341-342 (2012) 68-72.

DOI: 10.4028/www.scientific.net/amr.341-342.68

[10] S. H. Mannan, D. J. Williams, D. C. Whalley and A. O. Ogunjimi, Models to determine guidelines for the anisotropic conducting adhesives joining process, chapter 4 in Conductive Adhesives for Electronics Packaging edited by Johan Liu, Electrochemical Publications Ltd, June (1999).

[11] H. Ando, Y. Yamada, and Y. Suga, Anisotropic Conductive Film, Electronic Material, (1995) 72-76.

[12] Y. Yamada, ACF for Fine Pitch Connection, Proceedings of Fine Process Technology, Japan '95, Tokyo, Japan, (1995) R12.

[13] S. Ghahramani, Fundamentals of probability, Prentice Hall, 2nd edition, (2000).
