Novel Control Platform Development for PMLSM Drive System Based on Virtual Instrument

Abstract:

A novel control platform for the permanent magnet linear synchronous motor (PMLSM) drive system has been built up based on virtual instrument (VI) and relavant data acquisition card (DAQ) devices. In the traditional control platform, it mostly depends on digital signal processor (DSP), which needs a lot of time to further develop the interface between the personal computer (PC) and operators, and its computational capability is not strong than computer. To overcome these shortages, a novel control platform is presented on the base of one PC, one LabVIEW, and one multifunctional data acquisition card. Firstly, a space vector pulse width modulation (SVPWM) signal source is executed in the VI. Then in order to improve the precision of control system, the field oriented control (FOC) is proposed for the PMLSM. Finally comprehensive experiments verify with relative simulations.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 530-535
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.530
• Online since: September 2013
• Authors: Jian Xun Jin, Wei Xu, Yan Chen, You Guang Guo, Jian Guo Zhu
• Keywords: Field Oriented Control (FOC), LabVIEW, Permanent Magnet Linear Synchronous Motor (PMLSM), Space Vector Pulse Width Modulation (SVPWM)

References

[1] Y. S. Kung, Design and implementation of a high-performance PMLSM drives using DSP chip, IEEE Transactions on Industrial Electronics, vol. 55, no. 3, pp.1341-1351, March (2008).

DOI: 10.1109/tie.2007.909736

[2] C. L. Wang, Y. D. Zhang, and L. Zhao, Design of vertical transportation system driven by permanent magnet linear synchronous motor signal acquisition, 2012 International Conference on Industrial Control and Electronics Engineering, pp.2033-2035, Aug. (2012).

DOI: 10.1109/icicee.2012.540

[3] F. J. Lin, P. H. Chou, and C. S. Chen, DSP-based synchronous control of dual linear motors via sugeno type fuzzy neural network compensator, 2011 International Conference on Electrical Machines and Systems, pp.1-6, Aug. (2011).

DOI: 10.1109/icems.2011.6073468

[4] Y. W. Zhu, S. M. Jin, K. S. Chung, and Y. H. Cho, Control-based reduction of detent force for permanent magnet linear synchronous motor, IEEE Transactions on Magnetics, vol. 45, no. 6, pp.2827-2830, June (2009).

DOI: 10.1109/tmag.2009.2018681

[5] Z. G. Wang, J. X. Jin, Y. G. Guo, and J. G. Zhu, SVPWM techniques and applications in HTS PMSM machines control, Journal of Electronic Science and Technology of China, vol. 6, no. 2, pp.191-197, (2008).

[6] B. Vafakhah, J. Salmon, and A. M. Knight, A new space-vector PWM with optimal switching selection for multilevel coupled inductor inverters, IEEE Transactions on Industrial Electronics, vol. 57, no. 7, pp.2354-2364, July (2010).

DOI: 10.1109/tie.2009.2038939

[7] S. Pan, J. M. Pan, and Z. H. Tian, A shifted SVPWM method to control DC-link resonant inverters and its FPGA realization, IEEE Transactions on Industrial Electronics, vol. 59, no. 9, pp.3383-3391, Sept. (2012).

DOI: 10.1109/tie.2011.2173891
