Simulation on the Life Expectancy of Fine Blanking Punch for Recreation Vehicle Seat Recliner Sector Tooth

Abstract:

The fine blanking product cost can be increased, however, while the precise fine blanking tool and high cost fine blanking press are required. Therefore it is very important to design the fine blanking tool in view of life expectancy of punch. In this paper the fatigue simulation of fine blanking tool punch for recreation vehicle seat recliner sector tooth was conducted with using the commercial FEA software ANSYS in order to evaluate the life expectancy of the fine blanking tool punch. Initially, the material properties were tested, the fine blanking tool was designed for production experiments. The modelling of tool elements and the fatigue simulation according to repeated loads was conducted. As a result of fatigue simulation, the fine blanking tool punch for seat recliner sector tooth had been fractured with 11,121 strokes. In the fine blanking production experiments, the fine blanking tool punch had to be regrinded, after it was used with 10,160 strokes. It would be found that the fatigue simulation of the fine blanking tool punch was conducted with an error of 8.6% .

• Periodical: Applied Mechanics and Materials (Volume 619)
• Pages: 63-67
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.619.63
• Online since: August 2014
• Authors: Jong Deok Kim*, Hyun Jun Ko, Jeong Jin Kang, Sang Yong Lee, Sung Hee Lee
• Keywords: Fatigue, Fine Blanking, Life Expectancy, Punch, Seat Recliner Sector Tooth

References

[1] Taylan Altan, Metal Forming Handbook/Shuler GmbH, Springer-Verlag, Berlin Heidelberg New York (1998), Chapter 4.

[2] Jong-Deok Kim, Heung-Kyu Kim, Young-Moo Heo, Sung-Ho Chang, A study on the effect of V-ring position on the die roll height in fine blanking for special automobile seat recliner gear, Advanced Materials Research, Vols. 383-390(2012), pp.7122-7127.

DOI: 10.4028/www.scientific.net/amr.383-390.7122

[3] Jong-Deok Kim, Heung-Kyu Kim, Young-Moo Heo, Sung-Ho Chang, A study on die roll height of special automobile seat recliner gear according to die chamfer shape in fine blanking tool, Advanced Materials Research, Vols. 121-126(2012), pp.3694-3699.

DOI: 10.4028/www.scientific.net/amm.121-126.3694

[4] K. Lange, F. Birzer, P. Hoefel, A. Muhoty, H. Singer, Cold forming and Fineblanking, Edelstahlwerke Buderus AG, Feintool AG Lyss, Hoesch Hohenlimburg GmbH, Kaltwaltzwerk Brockhaus GmbH(1997), pp.154-165.

[5] W. Blatter, in: Introduction into the technology fine blanking tools, Incheon, KAITECH (1991).

[6] Jong-deok Kim, Young-moo Heo, Si-tae Won, Sung-hee Lee, Sang-chul Lee, An Evaluation of the Fine Blanking Simulation for Seat Recliner Sector Tooth, in Proc. 2014 MDMAE Conf. (2014), pp.336-341.

[7] J. L. Bassani, Yield characterization of metals with transversely isotropic plastic prop-erties, Int. J. Mech. Sci., Vol. 19(1977), p.651∼156.
