Self-Calibration of Coupling Error for 3-DOF Displacement Measurement of Planar Working Stage Based on Two Planar Gratings

Abstract:

A self-calibration method of coupling error is presented for 3-DOF displacement measurement of a planar moving stage based on two planar gratings. The self-calibration method using Fourier series is developed to extract the periodic systematic errors from the coupling errors. The extracted periodic systematic errors are compensated. Experiments are conducted to validate the validity of the self-calibration method and experimental results indicate that the coupling errors in x and y directions are reduced by 2 and 1.5 times respectively. It can be therefore concluded that the self-calibration method is suitable for the 3-DOF displacement measurement of a planar moving stage to improve the positioning accuracy.

• Periodical: Applied Mechanics and Materials (Volume 870)
• Pages: 135-140
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.870.135
• Online since: September 2017
• Authors: Yong Meng Liu*, Ze Lin Li, De Hao Du, Mao Qiang Yuan, Jing Zhi Huang, Jiu Bin Tan
• Keywords: 3-DOF Displacement Measurement, Coupling Error, Planar Grating, Planar Moving Stage, Self-Calibration

References

[1] Choi Y. M., Gweon D. G., A high-precision dual-servo stage using halbach linear active magnetic bearings, IEEE/ASME Transactions on Mechatronics. 16(5) (2011) 925-931.

DOI: 10.1109/tmech.2010.2056694

[2] Fan K C, Wang H Y, Ye J K., Contouring error compensation on a micro coordinate measuring machine, International Society for Optics and Photonics. 83213 (2011) I1-I11.

[3] X. Li, W. Gao, H. Muto, Y. Shimizu, S. Ito, and S. Dian, A six-degree-of-freedom surface encoder for precision positioning of a planar motion stage, Precision Engineering. 37(3) (2013)771–781.

DOI: 10.1016/j.precisioneng.2013.03.005

[4] Ellis J D, Baas M, Joo K N, Theoretical analysis of errors in correction algorithms for periodic nonlinearity in displacement measuring interferometers, Precision Engineering. 36(2) (2012) 261-269.

DOI: 10.1016/j.precisioneng.2011.10.008

[5] A. Kimura, W. Gao, W. J. Kim, K. Hosono, A sub-nanometric three-axis surface encoder with short-period planar gratings for stage motion measurement, Precision Engineering. 36(4) (2012) 576–585.

DOI: 10.1016/j.precisioneng.2012.04.005

[6] Zhu Y, Hu C, Hu J, Accuracy and simplicity oriented self-calibration approach for two-dimensional precision stages, IEEE Transactions on industrial electronics. 60(6) (2013) 2264-2272.

DOI: 10.1109/tie.2012.2194970

[7] Ye J, Takac M, Berglund C N, An exact algorithm for self-calibration of two-dimensional precision metrology stages, Precision Engineering. 20(1) (1997)16-32.

DOI: 10.1016/s0141-6359(97)00005-6

[8] Khalil W, Besnard S., Self calibration of Stewart-Gough parallel robots without extra sensors, IEEE Transactions on robotics and automation. 15(6) (1999) 1116-1121.

DOI: 10.1109/70.817674

[9] Jiwen Cui, Xueming Liu, Jiubin Tan, Self-calibration for 2-D ultra-precision stage, Optical and Precision Engineering. 20 (2012) 1960-(1965).

[10] Zhu Y, Hu C,  Hu J,  Chen Z, A transitive algorithm for self-calibration of two-dimensional ultra-precision stages, 2011 IEEE/ASME International Conference on IEEE, (2011)594-598.

DOI: 10.1109/aim.2011.6027114
