Design and Performance Evaluation of HVAC Systems with Thermal Load and Duct Sizing Considerations Theater Buildings

Abstract:

Climate change and rising global temperatures—up to 1.17°C over the past two decades—have intensified the need for energy-efficient building systems. The building sector contributes approximately 25% of global energy use and CO₂ emissions, with HVAC systems alone accounting for nearly 50% of a building’s total energy consumption. Despite this, limited research addresses HVAC performance optimization specific to high-occupancy spaces like theater buildings, which face unique thermal and airflow challenges. This study aims to design and evaluate a high-performance HVAC system for a theater building by analyzing thermal loads and optimizing duct sizing to enhance energy efficiency and occupant comfort. Using Panasonic’s simulation software, we conducted a comprehensive thermal load analysis across four zones of a theater facility. The results revealed peak cooling loads at 18:00 WIB, with Zone A requiring 66,882 W, Zone B 56,376 W, Zone C 62,492 W, and Zone D 34,291 W. The system was designed to maintain indoor conditions at 22°C and 65% relative humidity, with an airflow supply temperature of 12.8°C. The largest duct sizing was determined to be 90×60 in (equivalent to 79.8 in in diameter) in Zone A. The findings offer actionable insights for HVAC system design in large enclosed public spaces. By integrating detailed thermal load assessment and duct optimization, this study contributes to the development of more sustainable and energy-efficient building practices, supporting broader green building initiatives.

• Periodical: Applied Mechanics and Materials (Volume 931)
• Pages: 73-83
• DOI: https://doi.org/10.4028/p-AgeHi4
• Online since: February 2026
• Authors: Fayza Yulia*, Putu Mega Dana, Yustinus Bram, Kevin David Lokollo, Raden Wisnu W. Partakusuma
• Keywords: Cooling Capacity, Duct Sizing, HVAC System, Theater Building

References

[1] Khan, F.A., et al., The Influence of Design Parameters on the Operational Energy Carbon Emissions of a Commercial Building in Pakistan. 2025. 7(2): p. e70013.

[2] Lovrić, M., et al., Evidence driven indoor air quality improvement: An innovative and interdisciplinary approach to improving indoor air quality. 2025. 51(1): p. e2126.

DOI: 10.1002/biof.2126

[3] Li, M., et al., Study on enhanced fault diagnosis of chiller units in HVAC systems under the imbalanced data environment using GA-Optimized LightGBM. 2025. 330: p.115360.

DOI: 10.1016/j.enbuild.2025.115360

[4] Prof. Deepak Kumar Yadav, A.S., Ayush Chauhan, Gaurang Tripathi, Ankur Kumar, COOLING LOAD ESTIMATION OF A ROOM. International Research Journal of Engineering and Technology 2017. 04(05).

[5] Seem, J.E., Modeling of heat transfer in buildings. 1987: The University of Wisconsin-Madison.

[6] Chikwendu, O.C., et al., Sustainable HVAC Project Management: Strategies for Green Building Certification. 2025. 3(2): pp.14-28.

[7] Al-Habaibeh, A., et al., Enhancing the sustainability and energy conservation in heritage buildings: The case of Nottingham Playhouse. 2022. 11(1): pp.142-160.

DOI: 10.1016/j.foar.2021.09.001

[8] Gyurova, L. The Fluid Flow Simulation of the Thermal Comfort in Theatre. in ENVIRONMENT. TECHNOLOGY. RESOURCES. Proceedings of the International Scientific and Practical Conference. 2024.

DOI: 10.17770/etr2024vol3.8121

[9] ElHariry, G., W. Abdel-Samea, and E.E. Khalil. Heat Transfer and Air Flow Patterns Inside Air Conditioned Amphitheater. in 6th International Energy Conversion Engineering Conference (IECEC).

DOI: 10.2514/6.2008-5646

[10] Ahmadzadehtalatapeh, M.J.I.J.o.R.E.R., Improving the Energy Performance of HVAC Systems in Operating Theatres by Using Heat Recovery Devices. 2014. 4(3): pp.586-592.

[11] ASHRAE, Peak Cooling and Heating Load Calculations in Buildings Except Low-Rise Residential Buildings. 2007, American Society of Heating, Refrigerating and Air-Conditioning Engineers.

[12] ASHRAE, 2021 ASHRAE Handbook (Fundamentals). 2021, American Society of Heating, Refrigerating and Air-Conditioning Engineers.

[13] Indonesia, S.N., Tata cara perancangan sistem ventilasi dan pengkondisian udara pada bangunan gedung. 2001.

[14] ASHRAE, Thermal Environmental Conditions for Human Occupancy. 2023, ASHRAE.

[15] Association, S.M.a.A.C.C.N., HVAC Duct Construction Standards metal and Flexible 2020.
