Novel Laser Induced Metallization for Three Dimensional Molded Interconnect Device Applications by Spray Method

Abstract:

A novel laser induced metallization (LIM) is developed for 3 dimensional molded interconnect devices (3D-MIDs). A special laser-activable solution is firstly sprayed on top of the substrate, followed by laser direct structuring (LDS) and the electroless plating. The metal patterns can be transferred from the CAD data on almost any complex surface. Compared to the direct LDS, our spray method has smaller linewidth (30 μm) and much more flexibility on the substrate choosing. For example, the substrate can be plastic, glass, or ceramic. In addition, the laser-activable solution on top of the substrate also plays a role of the insulator. As a result, the multilayer patterns can be made by simply repeating the spray method on the same surface. Moreover, since this method is capable of making patterns layer-by-layer, the capacitors and inductances can be direct integrated with the circuit design. In this report, a 2G/3G/4G (all-in-one) antenna is tested by using our spray method. The return loss reaches the 3:1 VSWR standard, and the radiation efficiency is larger than 60% within the operation frequency.

• Periodical: Advanced Materials Research (Volume 1038)
• Pages: 69-73
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1038.69
• Online since: September 2014
• Authors: Min Chieh Chou, Tune Hune Kao, Meng Chi Huang, Wen Hua Zhang, Wei Yu Li*, Tzi Huei Lai
• Keywords: 3D-MID, Laser Induced Metallization, Multilayer, Spray

References

[1] D. Gries, Laser direct structuring creates low-cost 3D integrated circuits, Photonics Applied: Microelectronics processing, (2010).

[2] R. Schlüter, J. Kickelhain, M. Hüske, Ulmer Gespräche, Kunststoffe fur 3D-MIDs, Laserunterstützte, volladditive Metallisierung hochtemperaturbeständiger, May (2002).

[3] T. Leneke, S. Hirsch, B. Schmidt, A multilayer process for the connection of fine-pitch-devices on molded interconnect devices (MIDs), Circuit World, 35 (2009) 23-29.

DOI: 10.1108/03056120910953286

[4] J.Y. Chen, W.B. Young, Two-component injection molding of molded interconnect devices, International Journal of Material Science, 3 (2013) 90-96.

[5] A. Islam, H. Hansen, P.T. Tang, M. Jorgesen, S. Orts, Two component injection molding for MID fabrication, Prodeedings of ANTEC 2009 Annual Technical Conference, Chicago, USA. (2009).

[6] M, Kobayashi, Development of new molded interconnect device - innovative MID technology to realize a micro device, IEICE Tech. Rep., 107 (2007) 13-16.

[7] B. Hackmann, 3-Dimensional circuitry laser direct structuring technology (LPKF-LDSTM) for moulded interconnect fevices, (2006).

[8] N. Heininger, 3D LDS components for new production opportunities, Microwave Journal 55 (2012) 46-50.

[9] Goth, Putzo, and Franke, Aerosol Jet printing on rapid prototyping materials for fine pitch electronic applications, IEEE 61st Electronic Components and Technology Conference, pp.1211-1216, (2011).

DOI: 10.1109/ectc.2011.5898664

[10] Hoerber, Goth, Franke, and Hedges, Electrical functionalization of thermoplastic materials by Aerosol Jet Printing, IEEE 13th Electronics Packaging Technology Conference pp.813-818 (2011).

DOI: 10.1109/eptc.2011.6184525
