Optimized Design of Double-Loops Controller for Single-Phase Pulse Rectifier without LC Resonant Filter Circuit

Abstract:

Research on the lightweight issue of DC-link is an important direction in modern AC drive electric locomotive. Canceling LC filter circuit is an important way to achieve the goal of lightweight. Therefore, this paper focuses on single-phase pulse rectifier without LC filter circuit. The generation mechanism of DC voltage ripple and network-side current harmonics in grid-side converter is derived. Then, aiming to eliminate the current harmonics, the N-order notch filter and PR controller are introduced to the double-loops controller. The loop of voltage outer controller with N-order notch filter can filter out the ripple of DC-side voltage effectively without affecting the dynamic performance of the controller system. Meanwhile, the loop of current inner controller with PR controller can achieve zero steady-state error control to both the fundamental and harmonic current, and can suppress the low order harmonics in the line current effectively. Analysis shows that replacing the original L₂C₂ filter circuit with software controller is feasible. Finally, the validity and effectiveness of the proposed scheme are verified in computer simulation.

• Periodical: Advanced Materials Research (Volumes 1061-1062)
• Pages: 1031-1038
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1061-1062.1031
• Online since: December 2014
• Authors: Wen Ming Zhang*, Yong Xin Li, Xing Lai Ge, Yang Lu
• Keywords: DC-Link Lightweight, Harmonic Suppression, N-Order Notch Filter, PR Controller, Without LC Resonance Filter Circuit

References

[1] W. Song, K. Smedley, X. Feng, etl. One-Cycle Control of Induction Machine Traction Drive for High Speed Railway Part I Multi-pulse Width Modulation Region, in Proc. IEEE-IECON, 2010, pp.2346-2351.

DOI: 10.1109/iecon.2010.5674930

[2] Z Salam, C Goodman, Compensation of Fluctuating DC Link Voltage tor Traction Inverter Drive, in Proc. PEVSD, 1996, pp.390-395.

DOI: 10.1049/cp:19960946

[3] S. Somkun, P. Sehakul, and V. Chunkag, Novel Control Technique of Single-phase PWM Rectifier by Compensating Output Ripple Voltage, in Proc. ICIT, 2005, pp.969-974.

DOI: 10.1109/icit.2005.1600776

[4] Tsai M T, Tsai C. Energy Recycling for Electrical AC Power Source Burn-In Test[J]. IEEE Trans. Industrial Electronics, 2000, 47(4): 974–976.

DOI: 10.1109/41.857979

[5] Somkun S, Sehakul P, Chunkag V. Novel Control Technique of Single-phase PWM Rectifier by Compensating Output Ripple Voltage[C]. Proceedings of IEEE International Conference on Industrial Technology, 2005: 969-974.

DOI: 10.1109/icit.2005.1600776

[6] Zmood D N, Holmes D G. Stationary Frame Current Regulation of PWM Inverters With Zero Steady-State Error[J]. IEEE Trans. Power Electronics, 2003, 18(3): 814-822. ).

DOI: 10.1109/tpel.2003.810852

[7] J. Gao, Y. Zhang, F. Lin, etl. Research on Harmonic Current Elimination Method of Single-phase PWM Rectifiers [J]. Proceedings of the CSEE, 2010, 30(21): 32-39.

[8] Yukihiko Sato, Tomotsugu Ishizuka, Kazuyoshi Nezu, etl. A New Control Strategy for Voltage-Type PWM Rectifiers to Realize Zero Steady-State Control Error in Input Current[J]. IEEE transactions on industry applications, 1998, 34(3): 480-486.

DOI: 10.1109/28.673717

[9] Shoji Fukuda, Takehito Yoda. A Novel Current-Tracking Method for Active Filters Based on a Sinusoidal Internal Model[J]. IEEE transactions on industry applications, 2001, 37(3): 888-895.

DOI: 10.1109/28.924772

[10] Yepes A G, Freijedo F D, Doval-Gandoy J, Lopez 6, Malvar J and Fernandez-Comesana P. Effects of discretization methods on the performance of resonant controllers [J]. IEEE Transactions on Power Electronics, 2010, 25(7): 1692-1712.

DOI: 10.1109/tpel.2010.2041256
